action to the block definition, the "Property Lookup Table Dialog Box" on
page 157 is displayed
Specify action location: Specify a location in the block definition for the action

BACTIONSET

Specifies the selection set of objects associated with an action in a dynamic block definition
Shortcut menu: Select an action in the block definition. Right-click in the
Block Editor drawing area. Click Action Selection Set, and then click an option.
Command line:
Re-specifies the selection set of objects associated with an action by creating
a new selection set or by adding to or removing objects from the existing
selection set. You can only use the BACTIONSET command in the "Block
Editor" on page 139.
Select action: Select an action in the current dynamic block definition
Specify selection set for action object ["New" on page 120/"Modify" on page 121]
<New>: Enter modify to modify the existing selection set or press ENTER to create
a new selection set
New
If you selected a move, scale, rotate, flip, or array action, the following prompt
is displayed:
Specify selection set for action
Select objects: Select objects for the new selection set and then press ENTER
If you selected a stretch action, the following prompts are displayed:
Specify first corner of stretch frame or [CPolygon]: Specify the first corner of the
stretch frame or enter cpolygon to create a polygon of any shape as the stretch
frame
Specify opposite corner: Specify the opposite corner of the stretch frame
Select objects to stretch
Select objects: Select objects for the new selection set and then press ENTER
If you selected a polar stretch action, the following prompts are displayed:
Specify first corner of stretch frame or [CPolygon]: Specify the first corner of the
stretch frame or enter cpolygon to create a polygon of any shape as the stretch
frame
Specify opposite corner: Specify the opposite corner of the stretch frame
Specify objects to stretch
Select objects: Select objects to stretch
Specify objects to rotate only
Select objects: Select objects that will rotate only and not stretch
120 | Chapter 4
