7. Install the processor air duct. For instructions, see
Duct".
8. Install the server system cover. For instructions, see
9. Plug all peripheral devices and the AC power cable(s) into the server.

Removing the Server Board

1. Observe the safety and ESD precautions at the beginning of this book. See
Information".
2. Power down the server and unplug all peripheral devices and the AC power
cable(s).
3. Remove the server system cover. For instructions, see
Cover".
4. Remove the processor air duct. For instructions, see
Duct".
5. Remove the eight screws from the server board (see letter "A") and lift the server
board from the server system (see letter "B").
®
Intel Server System SR2520SA User's Guide
A
B

Figure 40. Removing the Server Board

"Installing the Processor Air
"Installing the System
"Removing the System
"Removing the Processor Air
AF001468
Cover".
"Safety
51
