Descriptions of Parameters
Setup Editor Parameters
Spring Switch
Controls the "memory" of each section of the optional ribbon controller for all zones. When the
value is On, the MIDI Controller message sent by the ribbon section "springs" back (the MIDI
Controller message's value returns to the value specified by the Spring Pos parameter--the way
the Pitch Wheel does on most instruments.
If the value is Off, the ribbon section remembers the last value it was sending when you released
the pressure on it. If you use a value of Off, we recommend that you also set the ribbon section's
Exit Value parameter to 0, so that any lingering values don't apply to other setups that don't
have entry values for that ribbon section.
Ribbon Mode
Affects the MIDI Controller values sent by the ribbon section for all zones. A value of Absolute
means that the value of the MIDI Controller message that the ribbon section sends is tied directly
to a physical location on the ribbon--in other words, touching a particular point on the ribbon
always generates the same value for the MIDI Controller message. If Spring Switch is On, this
means that when you touch the ribbon, the MIDI Controller value changes from the Spring Pos
value to whatever value corresponds to the location of your finger on the ribbon. If Spring Switch
is Off, touching the ribbon changes the MIDI Controller value from wherever it was when you
released the ribbon last time.
A value of Relative means that the position of your finger on the ribbon doesn't matter, and when
you press it, the MIDI Controller value picks up where you left off (either at the Spring Pos value
if Spring Switch is On, or whatever the last value was if Spring Switch is Off). When Ribbon
Mode is Relative, touching the ribbon doesn't change this value until you move your finger.
Setting Ribbon Mode to Relative works best when you also set Spring Switch to Off. In this case,
the ribbon works much like the mouse on a personal computer.
Spring Position (Spring Pos)
When Spring Switch is On, Spring Pos sets the "return" value for the ribbon section--that is, the
MIDI Controller message value sent by the ribbon section when you lift your finger from the
ribbon. This affects all zones in the setup. A value of 64 sets the zero point in the center of the
section; a value of 127 sets the zero point at the cable end of the section; a value of 0 sets the zero
point at the other end of the section.
The ribbon controller is a continuous controller, so each ribbon section also has the three
continuous-controller parameters (see page 5-12).
The Controllers Menu: Switch Controller Parameters
There are six controllers in the switch-controller group:
Button SW1
Button SW2
Button SW3
Button SW4
Each of these controllers has an independent set of parameters for each setup zone, as described
below.
5-14
Switch Pdl 1
Switch Pdl 2
