Descriptions of Parameters
Setup Editor Parameters

The Controllers Menu

The Controllers menu contains parameters that define the functions of the PC1's physical
controllers (wheels, knobs, pedals, buttons, and optional ribbon).
Each zone of every setup has a set of independently-programmable controller parameters.
Editing a parameter in one zone of a setup affects only that zone; it doesn't affect the other zones
in the setup, nor does it affect any other setup.
The internal setup (which defines numerous characteristics for every program in Program mode)
also has a separate set of these same parameters. Editing a parameter in the internal setup affects
all programs, but doesn't affect any setups.
There are three groups of controllers listed in the Controllers menu:
Continuous controllers
Switch controllers
Ribbon controller (a specialized continuous controller)
Each of these groups has a set of common but independently-programmable parameters. For
example, every continuous controller has a parameter called Ctrl Num; it determines which
MIDI message the controller sends. Editing the Ctrl Num parameter for one continuous
controller doesn't affect the value of Ctrl Num for any of the other continuous controllers.
To save space, we won't list every parameter for every controller. Instead, we identify the
controllers that belong to each group, then list the common parameters once for each group.

Entry Volume

Sets the volume level of the zone when you select the setup, by sending a MIDI Controller 7
message with the value you specify. You can set a value of None to prevent the message from
being sent when you select a setup.

The Controllers Menu: Continuous Controller Parameters

There are twelve controllers in the continuous-controller group:
Wheel 1 Up
Wheel 1 Down
Wheel 2
Mono Pressure (MPressure)
Knob A
Knob B
Knob C
Knob D
Each of the controllers in this group has the following three parameters.

MIDI Controller Number (Ctrl Num)

Determines which MIDI Controller message the physical controller sends. For example, Wheel 1
(also called the Pitch Wheel) has two assignments: One for when you move it up, and another for
5-12
Pedal 1
Ribbon 1
Ribbon 2
Ribbon 3
