6 Message Reference
Value
10
11
12
13
14
15
20
21
22
25
26
27
28
6.4.5

Error Indication

Synopsis:
Message issued to management to advise of errors or unexpected events
occurring within the protocol software.
Message Format:
Field Name
type
id
src
dst
rsp_req
hclass
status
err_info
len
84
Mnemonic
LIUS_SYNC_LOSS
LIUS_IN_SYNC
LIUS_AIS
LIUS_AIS_CLRD
LIUS_REM_ALARM
LIUS_REM_ALM_CLRD
LIUS_PCM_LOSS
LIUS_PCM_OK
LIUS_FRAME_SLIP
LIUS_BER5_OCRD
LIUS_BER5_CLRD
LIUS_BER3_OCRD
LIUS_BER3_CLRD
MESSAGE HEADER
Meaning
MGT_MSG_EVENT_IND (0x0008)
0 (unless shown below)
sending module id
MGMT_TASK_ID
0
0
Error Code (see below)
Timestamp
0
State
Frame Sync Loss
Frame Sync OK
AIS Detected
AIS Cleared
Remote Alarm
Remote Alarm Cleared
PCM Loss
PCM Restored
Frame Slip
BER > 1 in 100,000
BER5 cleared
BER > 1 in 1,000
BER3 cleared
