4 Configuration and Operation
4.4

Board Information Diagnostics

To assist in diagnosis of configuration problems and reporting hardware
details when encountering problems, a diagnostic display feature is available
in s7_mgt.
When s7_mgt is run with the –d command line option, a diagnostic display of
board hardware parameters is generated in this format following
configuration of the board.
S7_MGT Board identification: board_id 0
The parameters are as described below:
Table 9: Board Diagnostics – Hardware Parameters
Board type
Hardware revision
RAM size
Interface type
RTB switch
ADDR switch
BOOT switch
Shelf
Slot
Firmware
Electronic serial number
License serial number
26
Board type: 2 (SPCI)
Hardware revision: 0
RAM size: 0x00000000
Interface type: 0
RTB switch: 0
ADDR switch: 0
BOOT switch: 8
Shelf: 0
Slot: 0
Firmware: V1.02
Electronic serial number: 01-000007e09eb9-8a
License serial number: 02-0000008c92f7-72
Parameter Description
Board types are reported as follows:
2 SPCI2S or SPCI4
The board hardware revision number.
The on-board RAM size.
Parameter not supported for DSI SPCI Boards. Value
returned equals 0.
Parameter not supported for DSI SPCI Boards. Value
returned equals 0.
Geographic addressing switch setting, that is, the
address at which the board appears when the –o3
feature of ssds is used.
The setting of the board's rotary switch labeled "Boot".
Default setting - 8.
Parameter not supported for DSI SPCI Boards. Value
returned equals 0.
Parameter not supported for DSI SPCI Boards. Value
returned equals 0.
Firmware revision number.
The board's electronic serial number.
License serial number. The serial number of the fitted
license button (all zero's if none found).
