Description

Event Type

This message is used to convey the status of a board reset operation (success
of failure) to the user. The status is indicated in the status field of the
message header. The following table shows the possible Event Type values:
Value
0x60
0x62
0x66
0x67
6.2.4

Board Configuration Request

Synopsis:
Message sent to a board immediately after starting the code running to
provide protocol configuration parameters.
Note: When using s7_mgt, this message is generated by s7_mgt and must not be
generated by the user.
Message Format:
Field Name
type
id
src
dst
rsp_req
hclass
status
err_info
len
Offset
0
2
4
6
®
Dialogic DSI SPCI Network Interface Boards Programmer's Manual Issue 5
Meaning
Reset successful
Board failure
License validation failure
License appears corrupt
MESSAGE HEADER
Meaning
MGT_MSG_CONFIG0 (0x7F10)
0
Sending module's module_id
MGMT_TASK_ID (0x8e)
used to request a confirmation
0
Status Response (if confirmation requested)
0
68
PARAMETER AREA
Size Name
2 config_type (Must be set to 2)
2 flags
2 l1_flags
2 l2_flags
