Dialogic DSI SPCI Network Interface Boards Programmer's Manual page 71

Dialogic
Mode
local st local ts
1 * *
2 * *
3 * *
4 * *
5 * *
6 * *
10 * *
11 * *
12 * *
If a parameter is not required, it must be set to zero.
local_stream
The local stream defines which local stream to use for all the modes of
operation. The local streams are either an liu_id or a special identifier to allow
connection to the signaling processor as follows:
Local Stream
0 ... 3
131 (0x83)
local_slot
The local slot defines which timeslot on the local stream to use for all the
modes of operation. The local slot value has the following valid ranges
depending on the type of local stream:
Local Stream Type
Local stream to E1 LIU
Local stream to T1 LIU
Local stream to signaling processor
mode
The value of the mode parameter determines which of the following
operations to perform.
mode = 1 : Make a simplex connection from a timeslot on the CT bus to a
timeslot on the local bus. Using parameters local_stream, local_slot,
source_stream and source_slot, to specify the local and CT bus timeslots
respectively.
®
DSI SPCI Network Interface Boards Programmer's Manual Issue 5
Required Parameters
source st source ts
* *
* *
* *
* *
Connected to
liu_id 0 ... 3
Signaling Processor
dest st dest ts
* *
* *
Local Slot Range
1 ... 31
1 ... 24
0 ... 3
pattern
*
