6.2

General Configuration Messages

6.2.1

SSD Reset Request

Synopsis:
Message sent to SSD once at initialization to set up run-time options.
Note: When using s7_mgt, this message is generated by s7_mgt and must not be
generated by the user.
Message Format:
Field Name
type
id
src
dst
rsp_req
hclass
status
err_info
len
Offset
0
1
3
4
22
Description:
This message is used during initialization by the application to reset the ssd
module and set up its run-time parameters.
Parameter Description:
mgmt_id
The module_id of the management module, to which ssd sends board status
indications.
®
Dialogic DSI SPCI Network Interface Boards Programmer's Manual Issue 5
MESSAGE HEADER
Meaning
SSD_MSG_RESET (0x7680)
0
Sending module's module_id
SSD_TASK_ID (0x20)
used to request a confirmation
0
Status Response (if confirmation requested)
0
24
PARAMETER AREA
Size Name
1 module_id - must be set to SSD_TASK_ID
2 reserved – set to zero
1 mgmt_id
18 reserved – set to zero
2 num_boards
39
