Description:
This message is issued by s7_mgt on completion of the initial configuration
sequence and indicates either success (status=zero) or an error condition
that occurred during configuration. The message is only issued when s7_mgt
is run with the –i command line option specifying the module_id of the
Notification Module to which the message is sent. For example:
s7_mgt –i0x2d
Note: It is recommended that the user invoke this option and then wait for the
API_MSG_CNF_IND message to ensure the application does not attempt to send
messages until initial configuration is complete.
Parameter Description:
Completion Status
The result of initial configuration coded as follows:
Value
0
1
2
3
4
6.4.3

Clock Event Indication

Synopsis:
Message issued by the board to indicate on-board clocking related events.
Message Format:
Field Name
type
id
src
dst
rsp_req
hclass
status
err_info
len
®
Dialogic DSI SPCI Network Interface Boards Programmer's Manual Issue 5
Success
Error opening config.txt file
Syntax or value error in config.txt file
Error during configuration (invalid parameters)
Error during configuration (no response)
MESSAGE HEADER
Meaning
MVD_MSG_CLK_IND (0x0e23)
0
MVD_TASK_ID
0xdf
0
0
Event ID (see below)
Reserved for future use
0
Meaning
81
