6 Message Reference
Run Mode
Value
1
2
3
25
4
5
26
6
7
See section 2.3.2
the DSI SPCI Boards.
Status Response
The confirmation message (if requested) indicates success by status of zero.
No status values indicating errors are defined.
6.2.3
Board Status Indication
Synopsis
Message sent to the application on completion of the reset and download
sequence or on detection of a board status event.
Format
Field Name
type
id
src
dst
rsp_req
hclass
status
err_info
len
42
Run Mode
Protocols selected to run on the board
Mnemonic
DTI
Digital Trunk Interface only, no protocol software. This
mode does NOT require the use of a software license
button.
MTP2
MTP2 protocol only.
MTP
MTP3 plus MTP2 protocols.
ISUP-S
ISUP, small version, plus all MTP.
ISUP
ISUP, regular version, plus all MTP.
ISUP-L
ISUP, large version, plus all MTP.
TUP-S
TUP, small version, plus all MTP.
TUP
TUP, regular version, plus all MTP.
TUP-L
TUP, large version, plus all MTP.
Capacity
for details of the capacity for modules running on
MESSAGE HEADER
Meaning
SSD_MSG_STATE_IND (0x06a0)
board_id
SSD_TASK_ID (0x20)
mgmt_id for SSD
0
0
Event Type (see below)
0
0
