6 Message Reference
num_boards
The maximum number of boards that ssd is required to manage. This must
not exceed 16.

Status Response

The confirmation message (if requested) indicates success by status of zero.
On error, the following value can be found in the status message
confirmation.
Value
2
6.2.2

Board Reset Request

Synopsis:
Message sent to SSD to cause a single board to be reset and a code file
downloaded.
Note: When using s7_mgt, this message is generated by s7_mgt and must not be
generated by the user.

Message Format:

Field Name
type
id
src
dst
rsp_req
hclass
status
err_info
len
Offset
0
2
6
24
40
Mnemonic Description
SSD_BAD_PARAM The SSD Reset Request message was incorrectly formatted.
MESSAGE HEADER
Meaning
SSD_MSG_RST_BOARD (0x7681)
board_id
Sending module's module_id
SSD_TASK_ID (0x20)
used to request a confirmation
0
Status Response (if confirmation requested)
0
26
PARAMETER AREA
Size Name
2 board_type
4 phy_id
18 code_file
2 run_mode
