LIU Control Request

Synopsis:
Message sent by the application to dynamically control operation for a Line
Interface Unit (LIU). Allows setting of outgoing alarms and diagnostic
loopbacks.
Message Format:
Field Name
type
id
src
dst
rsp_req
hclass
status
err_info
len
Offset
0
1
2
3
Description:
This message is sent to the DSI SPCI Board to perform dynamic changes to
the operation of the Line Interface Unit. It allows the user to control
generation of AIS (Blue alarm) and RAI (Yellow alarm) and to activate various
diagnostic loopback modes.
The confirmation message (if requested) indicates success by status of zero.
Parameter Description:
ais_gen
The mode used to generate the Alarm Indication Signal (Blue Alarm) taken
from the following table:
®
Dialogic DSI SPCI Network Interface Boards Programmer's Manual Issue 5
MESSAGE HEADER
Meaning
LIU_MSG_CONTROL (0x7e35)
liu_id
Sending Module ID
MVD_TASK_ID (0x10)
used to request a confirmation
0
Status Response (if confirmation requested)
0
16
PARAMETER AREA
Size Name
1 ais_gen
1 rai_gen
1 loop_mode
13 Reserved for future use, must be set to zero.
57
