Dialogic DSI SPCI Network Interface Boards Programmer's Manual page 58

6 Message Reference
rai_gen
The mode used to generate the Remote Alarm Indication (Yellow Alarm)
taken from the following table:
loop_mode
The diagnostic loop back mode taken from the following table:
Status Response
The confirmation message (if requested) indicates success by status of zero.
On error, the following status values can be found in the confirmation
message.
Value
0x01
0x02
0x03
58
ais_gen
0 Do not change AIS / Blue alarm generation mode.
1 Disabled - do not generate AIS / Blue alarm.
2 Enabled - generate AIS / Blue alarm.
rai_gen
0 Do not change RAI / Yellow alarm generation mode.
1 Disabled - do not generate RAI / Yellow alarm.
2 Forced active - generate RAI / Yellow alarm.
3 Automatic generation of RAI / Yellow alarm upon loss of
synchronization.
loop_mode
0 Do not change diagnostic loop back mode.
1 Disabled - remove any diagnostic loop.
2 Payload loopback.
3 Remote loopback.
4 Local loopback.
Mnemonic Description
None Invalid framer ID.
None Invalid message length.
None Control parameters are not consistent with the type of device being
controlled or with each other.
Description
Description
Description
