6 Message Reference
timeslot
The timeslot number on the T1/E1 line interface unit on which the fixed data
is transmitted. The valid range for timeslot is 1 to 31 for an E1 interface and
1 to 24 for a T1 interface.
pattern
The value of the fixed data to be generated. The value must be in the range 0
to 255. Typical values are 0xff for an "all ones" idle pattern, or 0x2a for an
ITU-T E1 idle pattern.
Status Response
The confirmation message (if requested) indicates success by status of zero.
On error, the following status values can be found in the confirmation
message.
Value
0xd2
0xd3
0xff
6.3.9

Reset Switch Request

Synopsis:
Resets the digital switch to its default state in accordance with the current
board configuration.
Message Format:
Field Name
type
id
src
dst
rsp_req
hclass
status
err_info
len
68
Mnemonic
MVIP_INVALID_STREAM
MVIP_INVALID_TIMESLOT
None
MESSAGE HEADER
Meaning
MVD_MSG_RESETSWX (0x7e00)
0
Sending Module ID
MVD_TASK_ID (0x10)
used to request a confirmation
0
0
0
0
Description
Invalid stream specified in listen request.
Invalid timeslot specified in listen request.
Fixed pattern generation request failed.
