Liu State Request - Dialogic DSI SPCI Network Interface Boards Programmer's Manual

Status Response
The confirmation message (if requested) indicates success by status of zero.
On error, the following status value can be found in the confirmation
message.
Value
0x01
0xff
6.3.5

LIU State Request

Synopsis:
Message sent by the application to read the current state of a Line Interface
Unit (LIU).
Message Format:
Field Name
type
id
src
dst
rsp_req
hclass
status
err_info
len
Offset
1
Description:
This message is sent to the DSI SPCI Board to read the current operating
state of a Line Interface Unit.
The user should always request a confirmation message. This indicates
success by status of zero and contains the current state in the parameter
area of the message.
®
Dialogic DSI SPCI Network Interface Boards Programmer's Manual Issue 5
Mnemonic Description
None Invalid framer ID.
None Invalid message length.
MESSAGE HEADER
Meaning
LIU_MSG_R_STATE (0x5e39)
liu_id
Sending Module ID
MVD_TASK_ID (0x10)
used to request a confirmation
0
Status Response (if confirmation requested)
0
1
PARAMETER AREA
Size Name
1 state
61
