Adaptec 133U2 - AAA RAID Controller User Manual

Adaptec 133U2 - AAA RAID Controller User Manual

Ci/o management software
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
U
'
G
SER
S
UIDE
A
CI/O M
S
DAPTEC
ANAGEMENT
OFTWARE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 133U2 - AAA RAID Controller and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Adaptec 133U2 - AAA RAID Controller

Summary of Contents for Adaptec 133U2 - AAA RAID Controller

  • Page 1 ’ UIDE CI/O M DAPTEC ANAGEMENT OFTWARE...
  • Page 2 691 South Milpitas Boulevard Milpitas, CA 95035 © 1999 Adaptec, Inc. All rights reserved. Adaptec, and the Adaptec logo are trademarks of Adaptec, Inc. which may be regis- tered in some jurisdictions. Printed in Singapore STOCK NO.: 512061-00, Rev. B MO 2/99...
  • Page 3 Adaptec CI/O Management Software User’s Guide...
  • Page 4 Copyright © 1999 Adaptec, Inc. All rights reserved. No part of this publication may be repro- duced, stored in a retrieval system, or transmitted in any form or by any means, elec- tronic, mechanical, photocopying, recording or otherwise, without the prior written consent of Adaptec, Inc., 691 South Milpitas Blvd., Milpitas, CA 95035.

  • Page 5: Table Of Contents

    Contents Getting Started Overview of Adaptec CI/O Management Software 1-2 Conventions 1-3 Installing CI/O Software Installing Adaptec CI/O Management Software on Windows NT Server or Workstation 3 Stopping CI/O Array Management Service 4.00 9 Modifying Automatic Start of the Services 10...
  • Page 6 Adaptec CI/O Management Software User’s Guide Reconnecting to a Server 3-6 Deleting a Server Address 3-7 Viewing a List of Current System Events 3-7 Entering and Viewing Preference Information 3-10 Changing Filter Options 3-10 Selecting Notification Settings 3-12 Configuring Email 3-13...
  • Page 7 Contents Viewing SCSI Device Information from an Array Controller 6-6 Rescanning the Server 6-6 Viewing Array Controller Information 6-8 Viewing Channel Information 6-10 Performing Array, Spare, and Disk Operations Performing Array Operations 7-2 Reconstructing an Array 7-2 Pausing I/O on an Array 7-5 Verifying Array Integrity 7-6 Blinking Array Drive Lights 7-7 Reactivating an Off-line Array 7-8...
  • Page 8 Adaptec CI/O Management Software User’s Guide Replacing a Spare 10-4 Replacing an Active Array Member 10-6 Responding to an Off-line Array 10-6 Notes on Replacing Disk Drives 10-8 Optimizing Array Performance 10-9 Read Caching 10-11 Write Caching 10-12 Other Performance Tips 10-13...

  • Page 9: Getting Started

    In this Chapter Overview of Adaptec CI/O Management Software Conventions ® ™ This document explains how to use the Adaptec CI/O Management Software to perform the following operations: Install and use Adaptec CI/O Management Software View SCSI devices Create arrays and perform array, spare, and disk operations...

  • Page 10: Overview Of Adaptec Ci/O Management Software

    Adaptec CI/O Management Software User’s Guide Overview of Adaptec CI/O Management Software This User’s Guide explains how to use the Adaptec CI/O Management Software most effectively. Use the Contents and Index to find instructions for specific software commands. You can use the...

  • Page 11: Conventions

    Getting Started Conventions This document uses the following typographic conventions: bold Used for key names (… press the Enter key …) and for options you are told to select (… select Configure SCSI Channels…). Helvetica Used for screen messages (…Save changes?…) and for text that must be typed exactly as shown.
  • Page 13 Modifying Automatic Start of the Services 2-10 Uninstalling the Adaptec CI/O Management Software 2-11 in Windows Installing Adaptec CI/O Management Software on a 2-12 Networked Windows 95/98 or NT Client 2-18 Installing the TIRPC Communications Module on NetWare Servers v4.11 and v.5.0...

  • Page 14: Windows Nt Server Or Workstation

    Adaptec CI/O Management Software User’s Guide This chapter describes how to install Adaptec CI/O Management Software on the following: ® Windows 95/98 or NT client ® Windows NT server or workstation Novell NetWare server UnixWare server It also describes how to install the TIRPC Communications Module...

  • Page 15: Installing Ci/O Software

    Installing CI/O Software Installing Adaptec CI/O Management Software on Windows NT Server or Workstation Follow these steps to install the Adaptec CI/O Management Software on a Windows NT Server: Start Windows NT. Insert the Adaptec CI/O Management Software CD-ROM in your CD-ROM drive.
  • Page 16 Adaptec CI/O Management Software User’s Guide Click on Next. The Setup Type Selection screen appears. Figure 2-2. Setup Type Selection Screen If you are setting up a Windows NT server, select Networked System and click on Next. If you are setting up a stand-alone Windows NT Workstation, select Stand-alone system and click on Next.
  • Page 17 Installing CI/O Software Click on Next. The Choose Destination Location screen appears. Figure 2-4. Choose Destination Location Screen Use the Browse button to select the pathname for your installa- tion folder or select the default path. Click on Next. The Select Components screen appears Note: If you are using a Stand-alone system (choice B)
  • Page 18 Adaptec CI/O Management Software User’s Guide Figure 2-5. Select Components Screen Select the components you want to install and clear the compo- nents you do not want to install. Click on Next. The Select Pro- gram Folder screen appears. Figure 2-6. Select Program Folder Screen...
  • Page 19 Installing CI/O Software Select the program folder from the existing folders list or type a new folder name. Click on Next. The Start Copying Files screen appears. If you previously selected Stand-alone system (choice B) in the Steup Type Selection (2-2) screen, the Compo- nents Selected will list only IO Manager Service and Console User Interface.
  • Page 20 Click on Finish. Wait while the system reboots. Note: The NT services for Adaptec CI/O Management Software are configured to start automatically at boot time. After installation you can start or stop these services through the Services icon in the Windows NT...

  • Page 21: Stopping Ci/O Array Management Service 4.00

    Installing CI/O Software To start the user interface for Adaptec CI/O Management Soft- ware, go to Start > Programs > Adaptec CI/O Management Software. Click the icon. Note: You must have the proper level of Adaptec CI/O Management Software password authorization to perform operations using the CI/O software.

  • Page 22: Modifying Automatic Start Of The Services

    Adaptec CI/O Management Software User’s Guide Figure 2-11. Services Repeat step 4 to stop NobleNet Portmapper. Modifying Automatic Start of the Services Double-click the My Computer icon. Double-click the Control Panel icon. Double-click the Services icon. 2-10...

  • Page 23: Uninstalling The Adaptec Ci/O Management Software In Windows

    CIOArrayManagerRPC Command, CIOArrayManagerRPC Event and NobleNet Portmapper. Uninstalling the Adaptec CI/O Management Software in Windows Follow these steps to uninstall the Adaptec CI/O Management Software in Windows: Double-click the My Computer icon. Double-click the Control Panel icon. Double-click the Add/Remove Programs icon.

  • Page 24: Installing Adaptec Ci/O Management Software On A Networked Windows 95/98 Or Nt Client

    Adaptec CI/O Management Software User’s Guide Installing Adaptec CI/O Management Software on a Networked Windows 95/98 or NT Client This section explains how to install the Adaptec CI/O Management Software on a networked client running under 32-bit Windows (Windows 95/98 or Windows NT).
  • Page 25 Installing CI/O Software Double-click on the My Computer icon and then double-click on the CD-ROM drive icon. – Click on Cio400 and then click on WINDOWS_95_NT. – Click on disk 1. Double-click on the Setup icon. The Welcome screen appears. Figure 2-13.
  • Page 26 Adaptec CI/O Management Software User’s Guide Click on Next. If you are running under Windows NT, the Setup Type Selection screen appears. This window does not appear if you are running under Windows 95/98. Figure 2-14. Setup Type Selection Screen Select Networked client (user interface) only and click on Next.
  • Page 27 Installing CI/O Software Click on Next. The Choose Destination Location screen appears. Figure 2-16. Choose Destination Location Screen Use the Browse button to select the pathname for your installa- tion folder or select the default path. Click on Next. The Select Program Folders screen appears.
  • Page 28 Adaptec CI/O Management Software User’s Guide Select the program folder from the existing folders list or type a new folder name. Click on Next. The Start Copying Files screen appears. Figure 2-18. Start Copying Files Screen Click on Next to begin copying files. Once the folders are cop- ied, the CI/O ReadMe file appears as shown in Figure Figure 2-19.
  • Page 29 The setup is now complete. Select Yes, I want to restart my computer now. Click on Finish. To start the user interface for Adaptec CI/O Management Soft- ware, go to Start > Programs > Adaptec CI/O Management Software. Click the icon.

  • Page 30: Installing The Tirpc Communications Module On Netware Servers V4.11 And

    Installing the TIRPC Communications Module on NetWare Servers v4.11 and v.5.0 Follow these instructions to install the TIRPC communication module: Insert the Adaptec CI/O Management Software CD-ROM in your DOS-mounted CD-ROM drive. Bring up the server using the following pathname: C:\> cd nwserver C:\nwserver>server...

  • Page 31: Installing The Adaptec Ci/O Management Software On Novell Netware Servers

    ETHERNET_II, which must be specified when loading the LAN driver. A LAN driver can be loaded multiple times for different ethernet frame types. Follow these steps to install Adaptec CI/O Management Software from a DOS-mounted CD-ROM drive for Novell NetWare v4.11 and Novell NetWare v5.0:...
  • Page 32 Adaptec CI/O Management Software User’s Guide Insert the Adaptec CI/O Management Software in your CD-ROM drive. Adaptec CI/O NWSETUP NLM supports installation from either the DOS drive or a netware volume. You need to mount or attach the CD-ROM drive to the system according to the Novell instructions.

  • Page 33: Installing Adaptec Ci/O Management Software On Unixware 7.0.X Servers

    UnixWare 7.0.x Servers This section explains how to install the Adaptec CI/O Management Software on UnixWare. The installation is a two-part process. First you need to mount the CD-ROM and then install the Adaptec CI/O Management Software. Note: Before you install Adaptec CI/O Management...

  • Page 34: Install The Adaptec Ci/O Management Software On Unixware V7.0.X

    Adaptec CI/O Management Software User’s Guide Install the Adaptec CI/O Management Software on UnixWare v7.0.x At the System Administration window, double-click on Software Management. Double-click on Application Installer. At the Install From menu, select Other from the drop-down menu. Click on Find Folder to open the View Folder window. Click on the correct mount-point for the CD-ROM.

  • Page 35: Uninstalling The Adaptec Ci/O Management Software On Unixware V7.0.X

    Installing CI/O Software Uninstalling the Adaptec CI/O Management Software on UnixWare v7.0.x Follow these steps to uninstall the Adaptec CI/O Management Software on UnixWare v7.0.x: In the System Administration window, double-click on Software Management. Double-click on Application Installer. In the Application Installer window, click on the cio40 directory.

  • Page 37: Entering And Viewing System Information

    Entering and Viewing System Information In this Chapter Entering and Viewing System Information Starting the Program Adding a New Server Address Viewing System Information Reconnecting to a Server Deleting a Server Address Viewing a List of Current System Events Entering and Viewing Preference Information 3-10 3-10 Changing Filter Options...

  • Page 38: Entering And Viewing System Information

    Entering and Viewing System Information Starting the Program Follow these steps to start the Adaptec CI/O Management Software. This assumes that the software is already installed and that communications have been established between the system and the networked clients or other consoles.
  • Page 39 Entering and Viewing System Information restarting the application.The configuration will automatically be saved when you exit the application. Follow these steps to add a new server address to Adaptec CI/O Management Software: Click the button. The Add Server dialog box appears, as shown in Figure 3-1.
  • Page 40 Adaptec CI/O Management Software User’s Guide Click OK to add the new server information. If the server name/address is not correct, you will see one of the following error messages – RPC transport error. This means that you entered a server address with correct IP syntax, but there is no server with this address.

  • Page 41: Viewing System Information

    Entering and Viewing System Information Viewing System Information Follow these steps to view systems currently managed by Adaptec CI/O Management Software: Click to open the System Monitor window. Each system is represented by an icon in the top part of the window. The...

  • Page 42: Reconnecting To A Server

    Click on the System Monitor window toolbar. Note: If you are running Adaptec CI/O Management Software from a networked client and the message Guest Access Disabled appears at this point, the system to which you are trying to connect does not allow remote users to view its configuration information.

  • Page 43: Deleting A Server Address

    When you delete a server address, the icon for the server no longer appears in the System Monitor window and you can no longer view information for that server or manage it with Adaptec CI/O Management Software. Follow these steps to delete a server address: Click to open the System Monitor window.
  • Page 44 Adaptec CI/O Management Software User’s Guide Follow these steps to view a list of current events in the System Monitor window: Click to open the System Monitor window. Event notifications appear in the bottom part of this window, as shown in Figure 3-2.
  • Page 45 Click Close when you are finished viewing the Event Detail dialog box. When you do this, you automatically notify Adaptec CI/O Management Software that you have read the event notification. – To mark all new event notifications from all systems without...

  • Page 46: Entering And Viewing Preference Information

    Adaptec CI/O Management Software User’s Guide Click the Filter button on the System Monitor window toolbar to filter the event notifications in this window by severity. (See Changing Filter Options below.) For example, you may only want to view critically important events at this time.
  • Page 47 Change the options as described above and click OK. The changed settings apply to this view only while it is open; the settings will return to the defaults if you close and reopen the view or if you restart Adaptec CI/O Management Software. 3-11...

  • Page 48: Selecting Notification Settings

    Selecting Notification Settings The notification settings determine how you are notified of events that occur on systems to which Adaptec CI/O Management Software is connected. The text describing these events appears in the list of current server events and the Historic Event Log.

  • Page 49: Configuring Email

    Entering and Viewing System Information Note: If you do not want to view the user interface, we recommend launching it as a status-bar icon (see page 3-20 for details). Select the defaults or click OK to save these settings. Configuring Email If you check the Email checkbox and click on the Configure email option the Connection Settings dialog box appears, as shown in Figure 3-6...
  • Page 50 Adaptec CI/O Management Software User’s Guide Click on the Recipient List tab to display the Recipient dialog box as shown in Figure 3-7. Figure 3-7. Recipient List Dialog Box In this dialog box you can add, modify, or remove recipients. If you select Add, the Add Recipient dialog box will appear as shown in Figure Figure 3-8.

  • Page 51: Viewing Historical Information

    Use the Historic Event Log to view historical information for any system to which you are connected. If you are running the console version of the Adaptec CI/O Management Software on a windows NT system, you can view information for this one system. If you are...
  • Page 52 Adaptec CI/O Management Software User’s Guide Click to open the Historic Event Log for the currently selected system, as shown in Figure 3-9. Figure 3-9. Historic Log Window View the historical event information for the system. New entries are added to the top of the list as they occur. To specify the event order, click on the column heading by which you wish to sort.

  • Page 53: Interpreting And Responding To Event Messages

    Entering and Viewing System Information Note: When you open the Historic Event Log, only the most recent log entries are initially retrieved from the system. If you scroll down beyond these entries, another group of entries is retrieved. This avoids the delay that might occur if an entire large log file were retrieved from the system at one time.

  • Page 54: Additional Preference Information

    Adaptec CI/O Management Software User’s Guide Additional Preference Information The information in this section describes how to use the Ping, Notification, Filter, Password and Launch tabs contained in the Preferences dialog box. Follow these steps to change or view preferences information:...
  • Page 55 Entering and Viewing System Information Click the Filter tab to view the Filter dialog box. Select or deselect the check boxes, to filter the types of messages that appear in the windows. We recommend that you select all the boxes so you are fully informed of server events. The Filter Dialog box appears as shown in Figure 3-4 on page 3-11.
  • Page 56 Figure 3-12. Figure 3-12. Launch Dialog Box Select how you want to initially view your application. You can start Adaptec CI/O Management Software in maximized mode or you can set it up as a status bar icon. Note:...

  • Page 57: Viewing Scsi Device Information

    Viewing SCSI Device Information In this Chapter Viewing SCSI Devices Viewing the SCSI Information Dialog Box Viewing SCSI Adapter and Array Controller Information Viewing SCSI Channel Information Rescanning the SCSI Adapters and Array Controllers 4-9 Differences in Rescan Between SCSI Adapters and Array Controllers Rescan Details Managing SCSI Adapters...

  • Page 58: Viewing Scsi Devices

    Adaptec CI/O Management Software User’s Guide Viewing SCSI Devices You can view the status of SCSI devices connected to one or more array controllers or SCSI adapters from the Physical Resources window in the Configuration View. The Physical Resources window contains the Graphical View as shown in Figure 4-1 and the Detailed View as shown in Figure 4-2.
  • Page 59 Viewing SCSI Device Information Figure 4-2. Physical Resources Window - Detailed View Follow these steps to view configuration information for an adapter or controller: Click to open the Storage Configuration window. Right-click the icon of the device and select Information from the drop-down menu.

  • Page 60: Viewing The Scsi Information Dialog Box

    Adaptec CI/O Management Software User’s Guide – Printer – Enclosure Management Processor The SCSI Device icons shown above represent physical devices that appear on the left side of the window. Physical means that the icons correspond to actual devices installed in the server, such as a SCSI drive or a CD-ROM drive.
  • Page 61 Viewing SCSI Device Information Click on the Description tab to display device information such as the manufacturer, model name, and revision number. Click on the Status tab to display the current status of the selected SCSI device and O/S usage, as shown in Figure 4-4. Figure 4-4.

  • Page 62: Viewing Scsi Adapter And Array Controller Information

    Adaptec CI/O Management Software User’s Guide Viewing SCSI Adapter and Array Controller Information When you right-click a SCSI adapter or array controller icon and select Information from the drop-down menu, the Controller Information dialog box appears. Figure 4-5. Controller Information Dialog box - Description Tab Figure 4-5 displays the Description tab, while Figure 4-6 displays the Capabilities tab.
  • Page 63 Viewing SCSI Device Information Figure 4-6. Controller Information Dialog Box - Capabilities Tab Click the Capabilities tab, as shown in Figure 4-6, for a list of features that the selected device supports. Not all features appear for every product and the contents of the list may be different for SCSI and RAID products.

  • Page 64: Viewing Scsi Channel Information

    Adaptec CI/O Management Software User’s Guide Viewing SCSI Channel Information When you right-click a Channel icon and select Information from the drop-down menu, the Channel Information dialog box appears, as shown in Figure 4-7. Figure 4-7. Channel Information Dialog Box...

  • Page 65: Rescanning The Scsi Adapters And Array Controllers

    4-10 for information on discovery. Differences in Rescan Between SCSI Adapters and Array Controllers There are differences in the way the Adaptec CI/O Management Software rescans SCSI adapters versus array controllers. This is due mainly to differences in complexity between an array controller and a SCSI adapter.

  • Page 66: Managing Scsi Adapters

    I/O is present. Managing SCSI Adapters SCSI devices that are attached to an Adaptec SCSI adapter are managed differently than those attached to an array controller. For each device attached to an Adaptec AHA -2940U2W or similar adapters, the Adaptec CI/O Management Software checks the system to detect possible device failures.
  • Page 67 Poll phase every 3 minutes, which can be modified in the iomgr.ini file on the system. During this phase, the Adaptec CI/O Management Software performs the following steps: – Verifies that the number of host adapters is the same as in the Discovery phase –...
  • Page 68 Adaptec CI/O Management Software User’s Guide During this phase, the following are performed: – Iterates through all host adapters and devices – Gathers statistics for each host adapter or device This data is currently only available from SNMP or DMI interfaces.

  • Page 69: Configuring Arrays And Spares

    5-17 This chapter explains how to add and delete arrays and spares with the Adaptec CI/O Management Software. You must know the Adaptec CI/O Management Software password to add and delete arrays and spares. See Chapter 9, Setting Security Options, for more...

  • Page 70: Creating An Array

    Adaptec CI/O Management Software User’s Guide Creating an Array The following steps describe how to create an array with Adaptec CI/O Management Software. Note: When you create an array using different capacity drives, the smallest capacity drive used will determine the actual member size.
  • Page 71 Configuring Arrays and Spares Figure 5-1. Configuration - Graphical View Figure 5-2. Configuration - Detailed View The icons on the left side of the Storage Configuration window represent the server’s physical resources—the array controller products, channels, and SCSI devices installed in the system. The icons on the right side represent the system’s logical resources—the arrays and spares you define.
  • Page 72 To use a disk with a recognized partition in the array, exit from Adaptec CI/O Management Software, back up any data you want to keep, and delete the partition from the disk.
  • Page 73 Configuring Arrays and Spares Note: When you create the first array, the driver will reserve a portion of cache memory for system use. This may affect the amount of cache memory assigned to that array, if the value you select is larger than the actual memory remaining.
  • Page 74 Adaptec CI/O Management Software User’s Guide When all disks for the new array have been selected click Next. The Create Array - Name and Type dialog box appears, as shown in Figure 5-4. Figure 5-4. Create Array - Name and Type Dialog Box Type a name for the new array.
  • Page 75 Configuring Arrays and Spares Click Next. The Create Array - Advanced dialog box appears, as shown in Figure 5-5. Figure 5-5. Create Array - Advanced Dialog Box Select dedicated spares if desired. The disks in the list are the available disks you did not select as array members. The spare(s) you select should be at least as large as the smallest array member.
  • Page 76 Adaptec CI/O Management Software User’s Guide Note: If you want to distribute cache among arrays, do not use all of the available cache blocks for only one array. Select the desired optimization option from the Optimize Performance drop-down list. Refer to Optimizing Array Performance on page 10-9 for more details.

  • Page 77: Making An Array The First Virtual Device

    System Monitor window, depending on user options selected. Refer to Figure 3-5 on page 3-12 for more information. When initialization is complete, exit from Adaptec CI/O Management Software and reboot the system. After you reboot, you must partition the new array just as you would partition a new stand-alone disk drive.

  • Page 78: Deleting An Array

    Adaptec CI/O Management Software User’s Guide Click the icon in the Logical Resources window for the array that you want to make bootable. Right-click and select Make first virtual device from the drop- down menu. At the prompt, confirm that you want to make this array the boot device.

  • Page 79: Initializing An Array

    To delete an array with a recognized partition, back up any data you want to keep, and delete the partition from the disk. Then start Adaptec CI/O Management Software again and delete the array. When the confirmation message appears, confirm that you want to delete the array.
  • Page 80 To initialize an array with a recognized partition, exit from Adaptec CI/O Management Software, back up any data you want to keep, and delete the partition from the disk. Then start Adaptec CI/O Management Software again and initialize the array.
  • Page 81 Configuring Arrays and Spares To abort the initialization process (not recommended), click on the main toolbar to open the Activity View Window, select the icon, and click the Abort icon Note: Depending on the capacity of the array, it may take a long time to initialize an array, especially a very large RAID 5 array with many disks.

  • Page 82: Creating Dedicated Spares Or A Spare Pool

    Adaptec CI/O Management Software User’s Guide Creating Dedicated Spares or a Spare Pool Each RAID 1, 0/1, or 5 array can have dedicated spares, which automatically replace failed disks only for that array. You can create dedicated spares when you create the array, or you can add them to the array at a later time.
  • Page 83 Configuring Arrays and Spares Click to display the Create Spare dialog box, as shown in Figure 5-6. Figure 5-6. Create Spare Dialog Box Select the Adapter from the Adapter list box. If you want to dedicate the spare to a specific array, select Dedicated in the Spare type field and click the name of the array you wish to dedicate it to in the scrollable array list.
  • Page 84 To use a disk with a recognized partition as a spare, exit from Adaptec CI/O Management Software, back up any data you want to keep, and delete the partition from the disk.

  • Page 85: Deleting A Spare

    Configuring Arrays and Spares Deleting a Spare Follow these steps to delete a spare to use it as a stand-alone disk. Click to open the Storage Configuration window. Right-click the icon of the spare you want to delete and select Delete from the drop-down menu. You can also press the Delete key to delete the spare.

  • Page 87: Viewing Array And Device Information

    Viewing Array and Device Information In this Chapter Viewing Array Information Viewing Spare Information Viewing SCSI Device Information from an Array Controller Rescanning the Server Viewing Array Controller Information 6-10 Viewing Channel Information...
  • Page 88 Adaptec CI/O Management Software User’s Guide The Adaptec CI/O Management Software allows you to view information about arrays, spares, and SCSI devices on any system to which you have access. You view this information in the Storage Configuration window. Follow these steps to open the Storage Configuration window: Click to begin the Adaptec CI/O Management software.

  • Page 89: Viewing Array Information

    Viewing Array and Device Information Viewing Array Information When you right-click an Array icon in the Storage Configuration window and select Information from the drop-down menu, the Array Information dialog box appears. Figure 6-2 shows the Description Tab and Figure 6-3 shows the Status tab. Figure 6-2.
  • Page 90 Adaptec CI/O Management Software User’s Guide Figure 6-3. Array Information Dialog Box - Status Tab The following information appears in the Status tab of the Array Information dialog box: Dedicated spares: number of spare disks dedicated to this array. Available pool spares: number of pool spares available to protect this array.

  • Page 91: Viewing Spare Information

    Viewing Array and Device Information Viewing Spare Information When you right-click a Spare icon in the Logical Resources area of the Storage Configuration window and select Information from the drop-down list box, the Spare Information dialog box appears, as shown in Figure 6-4. Figure 6-4.

  • Page 92: Viewing Scsi Device Information From An Array Controller

    Adaptec CI/O Management Software displays icons for these devices in the Storage Configuration window. You may need to issue a Rescan command while Adaptec CI/O Management Software is running so it can “see” the new hardware configuration. You need to do a Rescan if...
  • Page 93 However, if you remove a disk that is an array member, replace it with another disk, and issue a Rescan command, Adaptec CI/O Management Software will detect that the new disk is no longer an array member.

  • Page 94: Viewing Array Controller Information

    Adaptec CI/O Management Software User’s Guide Viewing Array Controller Information When you right-click a controller icon and select Information from the drop-down menu, the Controller Information dialog box appears. Figure 6-5 shows the Information tab and Figure 6-7 shows the Capabilities tab.
  • Page 95 Viewing Array and Device Information Figure 6-6. Controller Information Dialog Box - Capabilities Tab The Capabilities tab of the Controller Information dialog box lists the features supported by this array controller. The list is informational only; you cannot enable or disable the capabilities on the list.

  • Page 96: Viewing Channel Information

    Adaptec CI/O Management Software User’s Guide Maximum Number of Pool Spares: lists the maximum number of pool spares per array that the product supports. Maximum Number of Dedicated Spares: lists the maximum number of dedicated spares per array that the product supports.
  • Page 97 Viewing Array and Device Information Status: current operational status of the channel (for example, Active, Inactive). Channel Type: type of this channel—for example, SCSI. Maximum Devices: maximum number of SCSI devices that the channel supports. The channel itself is not counted in this maximum number.

  • Page 99: Performing Array, Spare, And Disk Operations

    Performing Array, Spare, and Disk Operations In this Chapter Performing Array Operations Reconstructing an Array Pausing I/O on an Array Verifying Array Integrity Blinking Array Drive Lights Reactivating an Off-line Array Changing an Array Name Forcing a Spare 7-10 Performing Spare Operations Testing All Spares 7-10 Blinking the Spare Drive Light...

  • Page 100: Performing Array Operations

    Adaptec CI/O Management Software User’s Guide Adaptec CI/O Management Software allows you to perform a number of operations on arrays, spares, and stand-alone disks. Some of the operations are performed immediately; others can be scheduled for a later time, or scheduled to occur periodically at stated intervals (See Chapter 8, Scheduling and Monitoring Array Operations).
  • Page 101 Performing Array, Spare, and Disk Operations As long as the array member is physically functional, you can reconstruct it with the Reconstruct command. You can reconstruct the array immediately, or you can schedule the reconstruct to occur at a later time. Since the reconstruction process may take a long time, you may want to schedule it for a time when there is less activity on the system.
  • Page 102 Adaptec CI/O Management Software User’s Guide Note: When the spare is created, Adaptec CI/O Management Software should automatically start a Reconstruct operation on the array. If for some reason the reconstruct does not begin automatically, follow the remaining steps to perform it manually.

  • Page 103: Pausing I/O On An Array

    Performing Array, Spare, and Disk Operations Pausing I/O on an Array Use this operation to pause data I/O on an array while you replace a disk, reconnect a loose connection, etc. If your array enclosure supports hot swapping , you do not need to pause I/O to replace a disk.

  • Page 104: Verifying Array Integrity

    RAID 0/1 or RAID 1 array does not match. In Adaptec CI/O Management Software you can schedule the Verify operation to run later or schedule it to run at a regularly occurring interval.

  • Page 105: Blinking Array Drive Lights

    This allows you to see which physical drives actually form the array. Note: Adaptec CI/O Management Software does not support blinking the drive lights on CD-ROM drives or most other non-hard disk drives. Follow these steps to blink the drive lights of the disks in an array: Click to open the Storage Configuration window.

  • Page 106: Reactivating An Off-Line Array

    Adaptec CI/O Management Software User’s Guide Click OK to the drive lights from blinking. You can also click on the Stop blinking lights icon to stop all of the drive lights from blinking. Reactivating an Off-line Array An array may go off-line because a cable is disconnected or because you mistakenly removed the wrong disk while trying to replace a failed disk.

  • Page 107: Forcing A Spare

    Performing Array, Spare, and Disk Operations Select Rename from the drop-down menu.The Change Name dialog box appears. Type the new array name and click OK. At the prompt, confirm that you want to change the array name. This change appears immediately in the Storage Configuration window.

  • Page 108: Performing Spare Operations

    If an error message indicates that the pool spare is not at least as large as the smallest disk in the array, add a larger spare. Performing Spare Operations The following are spare operations available in Adaptec CI/O Management Software: Testing All Spares on page 7-10...

  • Page 109: Blinking The Spare Drive Light

    Performing Array, Spare, and Disk Operations Select OK if you want to test all spares immediately, or select Scheduled if you want to schedule the operation for a later time. If you select Scheduled, enter a starting time, starting day, and other information.

  • Page 110: Performing Disk Operations

    Adaptec CI/O Management Software User’s Guide Performing Disk Operations You can perform the following disk operations with a single disk or with a selected disk in an existing array: Blinking the Drive Light on page 7-12 Downing the Drive on page 7-13...

  • Page 111: Downing The Drive

    Hard drives that support this technology continually analyze their performance and generate an alert if they determine that the disk is likely to fail in the next few hours. Adaptec CI/O Management Software generates an event notification if it receives this alert, allowing you to replace the disk before it actually fails.
  • Page 112 Adaptec CI/O Management Software User’s Guide Note: Pause I/O cannot assure the same level of protection from electrical noise that you have when you replace a disk in an enclosure that supports hot swapping. Every time you use this feature, you should only perform one action—either disconnecting a drive or inserting a drive, but not both.

  • Page 113: Scheduling And Monitoring Array Operations

    Setting Scheduling Options Viewing and Managing Scheduled Activities Adaptec CI/O Management Software enables you to schedule certain kinds of operations to run at a later time, or to schedule them to run at regularly recurring intervals. You create these as scheduled...

  • Page 114: Setting Scheduling Options

    Otherwise, the scheduled activities may not run at the specified time. Do not change the system time while Adaptec CI/O Management Software is running. Instead, stop all CI/O components and RPC modules, change the system time, and then restart CI/O.
  • Page 115 Scheduling and Monitoring Array Operations If you select Scheduled, select Once, Periodically, Daily, or Weekly. Enter other information such as day of the week or start time as required. Note: If you are scheduling an array reconstruct you can only select the Once option. If you schedule an activity from a remote client to occur on a server in a different time zone, the activity will occur at the stated time relative to the server’s time zone.

  • Page 116: Viewing And Managing Scheduled Activities

    Test All Spares operation on the system. If you want to schedule this activity for a different time, first delete the one entered automatically by the Adaptec CI/O Management Software. Follow these steps to view and manage scheduled activities:...
  • Page 117 Scheduling and Monitoring Array Operations To view more detailed information about the activity, right- click the Activity icon and select Properties from the drop- down menu. The Scheduler dialog box appears, as shown in Figure 8-1. Click Cancel to close the dialog box. To change the priority of a Verify or Reconstruct operation that is currently running (as indicated by a moving icon), right- click the Activity icon on the left of the window and select...

  • Page 119: Setting Security Options

    When you install the Adaptec CI/O Management Software the initial password is set to adaptec. The password is case-sensitive and should not be capitalized. The network administrator can change the initial password for each server and controls users’...

  • Page 120: Changing The Password

    Adaptec CI/O Management Software User’s Guide Changing the Password You can change passwords from any client on the network. Follow these steps to change the Adaptec CI/O Management Software password: Click to open the System Monitor window. Then select the icon of the server whose password you want to change.

  • Page 121: Setting Password Time-Out Options

    Setting Password Time-out Options The Password Time-out options allow you to control the way in which users are prompted to enter the system’s Adaptec CI/O Management Software password when they issue commands to change a system’s array configuration. The Password Time-out options are set individually for each networked client.
  • Page 122 Adaptec CI/O Management Software User’s Guide – Prompt on all operations: Requires you to re-enter the password every time you issue a command to change array configuration. – Don’t prompt for X minutes: Requires you to re-enter the password at the stated time-out interval, whenever you issue commands to change the array configuration.

  • Page 123: Controlling Guest Access

    At this point, if you close and re-open Adaptec CI/O Management Software for that particular client, guest access privilieges for that client revert back to disabled. Note: If you do know the server’s password you can perform...
  • Page 124 Adaptec CI/O Management Software User’s Guide Right-click the server icon whose guest access setting you want to change and select Guest Access. When the Enable/Disable Guest Access dialog box appears, select or deselect the Enable Guest Access check box. Click OK to enter the change. Enter the password when you are prompted to do so.

  • Page 125: Managing Arrays And Spares

    Managing Arrays and Spares In this Chapter Responding to a Critical Array 10-2 10-4 Replacing a Spare Replacing an Active Array Member 10-6 Responding to an Off-line Array 10-6 Notes on Replacing Disk Drives 10-8 Optimizing Array Performance 10-9 10-11 Read Caching Write Caching 10-12...

  • Page 126: Responding To A Critical Array

    In addition, you should monitor the status of arrays at all times with Adaptec CI/O Management Software to detect arrays whose status is Critical. You can monitor arrays effectively by enabling the Pop- up Event Notification option so that a message appears on the screen whenever an array enters Critical status.
  • Page 127 Managing Arrays and Spares Click the Array icon and observe the Disk icons of the array members on the left side of the screen. One of the icons should look like this , indicating that the disk has failed. Right-click the icon and then select Blink from the drop-down menu to blink the drive light on the failed disk.

  • Page 128: Replacing A Spare

    Adaptec CI/O Management Software User’s Guide Insert the replacement drive and issue the Rescan command. If the array enclosure does not support hot swapping, pause I/O to the array before you continue. (Skip to Step 10 if the array enclosure supports hot swapping.) See Pausing I/O on an Array on page 7-5.
  • Page 129 Pause I/O again, insert the replacement drive, and allow I/O to resume. Use Adaptec CI/O Management Software to mark the new disk drive as a dedicated spare or a pool spare (see Creating Dedicated Spares or a Spare Pool on page 5-14).

  • Page 130: Replacing An Active Array Member

    Responding to an Off-line Array You can tell that an array is in off-line status if OFFLINE appears in the Array Status field in Adaptec CI/O Management Software or if the Array icon in the Storage Configuration window looks like this: .
  • Page 131 Managing Arrays and Spares recover the array data if an array went off-line due to disk failure. You were trying to replace a failed disk in a Critical, RAID 0/1, or RAID 5 array, but you mistakenly pulled the wrong disk out of the array enclosure.

  • Page 132: Notes On Replacing Disk Drives

    Adaptec CI/O Management Software User’s Guide Notes on Replacing Disk Drives We recommend that if you use hot swapping to replace a drive that supports tagged command queuing (TCQ), you replace it with a drive that also supports TCQ. Otherwise, a rescan may not detect that the drive has been swapped.

  • Page 133: Optimizing Array Performance

    Your array controller may have a built-in, onboard Read/Write caching feature that allows faster data I/O to arrays controlled by the card. The Adaptec CI/O Management Software allows you to define cache values for optimizing the performance of a specific application.
  • Page 134 Optimized Application list box. Select Caching enabled to enable caching on this array. When you enable caching, Adaptec CI/O Management Software assigns default values to the Read and Write Cache. Click the Edit button. The Performance Setting dialog box appears, as shown in Figure 10-2.

  • Page 135: Read Caching

    Managing Arrays and Spares Click Save to save the new performance setting. The changes are not written to disk until you exit the application. If a new performance setting has been successfully created, it will appear in the Optimize Performance for list box. When the Optimize Performance dialog box displays, click OK to save your changes.

  • Page 136: Write Caching

    Adaptec CI/O Management Software User’s Guide Write Caching There are two Write caches: the Write-back Cache and the Write- through Cache. Options for these caches can be adjusted separately for each array. Write-back Caching— this option defines the maximum Write command size (stated as a number of data blocks) that will be cached in the Write-back Cache.

  • Page 137: Other Performance Tips

    Managing Arrays and Spares Other Performance Tips If your array controller has multiple channels, you may be able to achieve better sequential data access when creating large arrays on powerful, high-end servers if some array members are connected to each channel. The array management software and drivers allow you to use disks of various sizes and makes in the same array.

  • Page 138: Selecting A Raid Level For An Array

    Adaptec CI/O Management Software User’s Guide Selecting a RAID Level for an Array The term RAID means Redundant Array of Independent Disks. An array is a grouping of disks that, by means of array management software, appears to the computer’s operating system as one large disk.
  • Page 139 Managing Arrays and Spares The array management software and firmware support RAID 0, RAID 1, RAID 0/1, and RAID 5 arrays. The advantages, disadvantages, and requirements of these RAID levels are as follows: RAID 0 Arrays Maximum Disks Allowed: 16 (or as allowed by your controller) Minimum Disks Allowed: 1 In a RAID 0 array, data is distributed, or striped, across the disks in...
  • Page 140 Adaptec CI/O Management Software User’s Guide RAID 0/1 Arrays Maximum Disks Allowed: 16 (or as allowed by your controller)(must be an even number) Minimum Disks Allowed: 4 RAID 0/1 disks use from two to eight pairs of disks. They are called mirrored arrays because both disks in each pair contain the same data.

  • Page 141: Configuration Settings

    Configuration Settings This appendix describes the configuration variables that control the appearance of the Adaptec CI/O Management Software user interface and the way in which array and system operations are carried out. The variables controlling the user interface appearance are in the Windows NT registry. The other variables are defined in the iomgr.ini .

  • Page 142: I/O Manager Settings

    The behavior of the I/O Manager may be changed by entries in the iomgr.ini file. [ASPIMODEL] DisableASPI = [Yes | No] I/O Manager options for management of Adaptec SCSI host adapters are configured by certain entries in the standard I/O Manager initialization file (iomgr.ini). The iomgr.ini file is located in the directory where you installed the Adaptec CI/O Management Software.
  • Page 143 Configuration Settings activated when a Discovery phase is active, the Poll phase is delayed until the Discovery phase completes. System design prevents a Statistics phase from being active when a Poll phase is activated. StatisticsInterval = n This option configures the frequency (in seconds) that the Statistics phase is run.
  • Page 144 Adaptec CI/O Management Software User’s Guide set to No, then the SCSI Manager will not check for instrumentation capable drivers. IOInstrumentation = [Yes | No] This option, if Yes, enables the SCSI Manager to collect I/O related instrumentation from instrumentation capable drivers. The default value is No.
  • Page 145 Configuration Settings number of test count debug events are seen; then the S.M.A.R.T. debug bit is turned back off. More than the requested count of debug events may be generated before the software can turn all debug events off. This option has no effect if S.M.A.R.T. is set to No. ForceHAWide16 = [Yes | No] ForceHAWide32 = [Yes | No] These two options are used to override the information obtained...
  • Page 146 The default is to manage all drivers beginning with AIC and AHA (although the driver names vary somewhat from system to system). The default allows popular Adaptec host adapters, such as the AHA-1540 and AHA-2940, to be managed by the SCSI Manager. The default is equivalent to the .INI specification:...
  • Page 147 Configuration Settings Note that putting an asterisk anywhere in the names makes all the other names meaningless. The specification: AccessibleDrivers = AIC, * would cause all drivers to be accessible, not just AIC drivers. Up to 100 drivers may be specified, and the maximum length of the string of driver names is 255 characters.
  • Page 148 Adaptec CI/O Management Software User’s Guide StatisticsCollectionInterval= This variable specifies the interval at which system statistics will be collected, assuming that the driver supports statistics collection. Values must be entered as whole numbers. The default value is 1. WarnAfterFirstPFAEvent= If set to Yes, this variable specifies that if S.M.A.R.T. events (PFA) are received from any drive the first event will be reported as a Critical event and all events after that will be reported as Warning events.
  • Page 149 Configuration Settings EnableRAID10= This variable enables or disables the option of creating RAID 0/1 arrays. If it is set to No users cannot create RAID 0/1 arrays. Valid values are Yes and No. The default is Yes. [ENCLOSUREMANAGER] EnabledEnclosureInterfaces=SAF-TE This specifies the enclosure management interfaces which are supported by CI/O.

  • Page 151: Bsaf-Te Enclosure Management

    These events can be viewed through the Historic Log window and are reflected in the Adaptec CI/O Management Software GUI. Also, CI/O will take the following actions: Reflecting the status on the enclosure: CI/O will take the...

  • Page 152: Viewing Enclosure Information

    Adaptec CI/O Management Software User’s Guide Viewing Enclosure Information Follow these instruction to view information on an enclosure: Click to enter the Storage Configuration window. Right-click the icon of the enclosure you wish to view and select Information from the drop-down menu. The Information dialog box- Enclosure Information tab is displayed as shown in Figure B-1.
  • Page 153 SAF-TE Enclosure Management The following information is displayed within the dialog box. (If an enclosure subsystem component has a problem, the symbol displayed next to the icon of that component.) Enclosure —displays the channel, SCSI ID, and LUN associated with the enclosure. Enclosure Information—displays the type, manufacturer, Product ID, and Enclosure ID.

  • Page 154: Viewing Subsystem Status Details

    Figure B-2. Component Status Dialog Box Temperature Sensors The status of the temperature sensors in the enclosure is displayed in the Temperature Sensors list box. Adaptec CI/O Management Software supports both threshold indicators and temperture indicators. If the enclosure contains at least one temperature indicator, the actual temperature is displayed.

  • Page 155: Fans

    SAF-TE Enclosure Management Note: Not all enclosure temperature sensors are supported by Adaptec CI/O Management Software. Fans The status of the fans in the enclosure is displayed in the Fans list as follows: Malfunctioning Not Installed Unknown Power Supplies The status of the power supplies in the enclosure is displayed in the...

  • Page 156: Identification Of Events

    Adaptec CI/O Management Software User’s Guide Identification of Events The Adaptec CI/O Management Software identifies events related to each SAF-TE enclosure. Each enclosure is identified by a unique address (bus/host adapter, channel, SCSI ID, and LUN). This address is specified for all events logged for that particular enclosure to allow easy identification of the enclosure.
  • Page 157 [ SAF-TE : unique address] Overall Temperature is out of normal range [ SAF-TE : unique address] Adaptec CI/O Management Software attempts to spin up all other fans to maximum capacity to avoid possible overheating. As a result of this action the following two...
  • Page 158 Adaptec CI/O Management Software User’s Guide “SCSI error” event is posted because the SAF-TE enclosure does not support some of the SAF-TE-interface commands. This situation does not require any intervention by the user. For each change in the status of the power supplies connected...

  • Page 159: Events For Devices Connected To Raid Boards

    SAF-TE Enclosure Management Events for Devices Connected to RAID Boards The following events are for devices connected to RAID Boards only. This information is optional depending on the enclosure implementation – Array rebuilding (all members of an array being rebuilt are identified) –...

  • Page 161: Glossary

    Glossary Using the Glossary This glossary contains terminology used in the Adaptec CI/O Management Software User’s Guide. Terms specific to CI/O will be designated as follows: This icon indicates a term as defined in CI/O. adapter, array Similar to an I/O adapter, but includes additional hardware to facilitate array operations.
  • Page 162 A set of conductors which connect the functional units in a computer. CI/O Stands for Comprehensive Input/Output. Refers to Adaptec’s CI/O Array Management Software. cache An intermediate storage area providing faster access for some portion of data.
  • Page 163 Glossary controller, storage In contrast to I/O Adapters, Storage Controllers provide additional functions such as RAID support and caching. The term is often used to refer to an Adapter with an on-board microprocessor which can process I/O commands. In practice, used interchangeably with Adapter. dedicated spare A spare disk which automatically replaces failed array members only for the array it is dedicated to.
  • Page 164 A file used to maintain information about controller activities or errors. event notifications settings Determines how you are notified of events that occur on systems to which Adaptec CI/O Management Software is connected. expand Increasing the capacity of an array by adding one or more disks.
  • Page 165 A low-level format completely cleans any data off of the drive. logical device A device which does not exist until configured by Adaptec CI/O Management Software. Stands for Logical Unit Number. The number assigned to a sub- device (logical unit) of a SCSI target. Each SCSI target can contain up to eight subdevices numbered 0 through 7;...
  • Page 166 Used in RAID levels 2, 3, 4 and 5. password time-out options Options that allow you to control the way in which users are prompted to enter the system’s Adaptec CI/O Management Software password when they issue commands to change a server’s array configuration.
  • Page 167 Glossary physical view A view showing physical devices such as SCSI disks, CD- ROMs, and enclosures. poll A validation of discovery information. pool of spares See spare pool. RAID Acronym for Redundant Array of Independent/Inexpensive Disks. Coined in 1987 by researchers at the University of California at Berkeley to describe a set of disk array architectures that provide fault-tolerance and improved performance.
  • Page 168 Adaptec CI/O Management Software User’s Guide members are redundant, since surviving members may collectively replace the data from a failed disk. referential integrity A set of constraints on the references between objects in a system meant to assure consistency; the state of such consistency.
  • Page 169 Glossary S.M.A.R.T Stands for Self-Monitoring Analysis and Reporting Technology. Hard drives that support this technology continually analyze their performance and generate an alert if they determine that the disk is likely to fail in the next few hours. spare pool A pool of multiple disks which automatically replace failed disks on any array on the controller.
  • Page 170 Arrays and spares which do not exist until they are configured on the server with Adaptec CI/O Management Software. virtual device order The sequence in which the server’s operating system detects the arrays, single disks, and other devices connected to the AAC controller when the server boots.
  • Page 171 Aborting a running activity 8-5 Activity Changing an activity’s priority 8-5 scheduling 8-2 Changing filter options 3-10 viewing activity queue 8-4 Channel information Adaptec CI/O Management viewing 4-8, 6-10 Software Choosing notification settings 3-12 starting 3-2 Client machine 12 Adaptec CI/O management...
  • Page 172 Adaptec CI/O Management Software User’s Guide Event notifications Password 9-1 changing 9-2 setting options for 3-10, 3-18 guest access 9-5 severity levels 3-17 time-out options 9-3 Password authorization 9, 17, 18, 21 Pausing/Resuming I/O Filter options, changing 3-10 to a device 7-13...
  • Page 173 Index viewing a list of 3-7 Server Historic Event Log changing filter options 3-10 notification settings 3-12 Server information viewing 3-15 viewing and editing 3-5 Server, scanning 6-6 Spare viewing information for 6-5 Spare pool creating 5-14 deleting disk from 5-17 Spare, dedicated deleting 5-17 Spare, forcing 7-9...
