Intel Server System SC5650BCDP TPS
Signal Type
PWOK = High
PWOK = Low
Logic level low voltage, Isink=4mA
Logic level high voltage, Isource=200μA
Sink current, PWOK = low
Source current, PWOK = high
PWOK delay: T
pwok_on
PWOK rise and fall time
Power down delay: T
3.1.8

FRU Data

The FRU data format is compliant with the IPMI, version 1.0 specification. To find the most
current version of these specifications you can go to
http:\\developer.intel.com/design/servers/ipmi/spec.htm.
3.1.8.1 Device Address Locations
The power supply device address location is as follows:
Revision 1.5
pwok_off
Power Supply FRU Device
Intel order number: E80367-002
Open collector/drain output from power supply. Pull-up
to VSB located in system.
Power OK
Power Not OK
MIN
0V
2.4V
100ms
1ms
A0h
Power Sub-System
MAX
0.4V
5.25V
4mA
2mA
1000ms
100μsec
200msec
