Intel SC5650BCDP Technical Product Specification page 13

®
Intel Server System SC5650BCDP TPS
Feature
Add-in PCI, PCI Slot6: One half-length (6.6 inches) PCI Express* Gen2 x8 connector with X8 link width
Express* Cards
Slot7 : One half-length (6.6 inches) PCI Express* Gen2 x8 connector with x8 link width
Slot5 : One half-length (6.6 inches) PCI Express* Gen2 x8 connector with x4 link width
Slot3 : One half-length (6.6 inches) PCI Express* x4 connector with x4 link width
Slot4 : One half-length (6.6 inches) 5V PCI 32 bit / 33 MHz connector
On-board ServerEngines* LLC Pilot II BMC controller
Video
Two 10/100/1000 NICs
LAN
Includes one tool-less fixed drive bay for up to six fixed drives
Hard Drive Options
Two USB ports
External front
connectors
Two tool-less, multi-mount 5.25-in peripheral bays.
Peripherals
One standard 3.5-in removable media peripheral bay.
Control Panel
Switches for power, NMI, and reset.
Integrated temperature sensor for fan speed management.
LEDs with standard control panel:
LEDs and displays
Intel
600-W PFC Intel validated PSU with integrated cooling fan.
Power Supply
One tool-less, 120-mm chassis rear fan.
Fans
One tool-less 120-mm PCI fan.
One tool-less 92-mm drive bay fan.
Revision 1.5
•
Integrated 2D video controller
•
64 MB DDR2 667 MHz Memory
One 82574LGbE PCI Express* Network Controller connects to the Gen2 x1
interface on the Intel
One 82567 Gigabit Network Connection that connects to the Gigabit LAN Connect
Interface / LAN Connect Interface on the Intel
Two 10/100/1000 Base-TX Interfaces through RJ-45 connectors with integrated
magnetics.
Link and Speed LEDs on the RJ-45 Connector.
LEDs for NIC1, NIC2, HDD activity, power status, and system fault status.
NIC1 Activity
NIC2 Activity
Power / Sleep
System Status
Hard Drive Activity
®
Light-Guided diagnostic LEDs:
Fan Fault
DIMM Fault
CPU Fault
5V-STBY
System State
POST Code Diagnostics
Intel order number: E80367-002
Description
®
5500 IOH chipset.
®
Product Overview
ICH10R
3
