External component identification

Top components

Display components

Item Component
(1) Integrated camera (select models only)
(2) Camera light (select models only)
(3) Camera mode switch
(4) Keyboard light
(5) Keyboard light button
(6) HP Fingerprint Sensor (fingerprint reader)
(7) Internal microphones (2)
6 Chapter 2 External component identification
Description
Records video, captures still photographs, and transmits
streaming video for video conferencing.
On: The camera is recording or streaming video or capturing
a still photograph.
●
To use macro mode, slide the switch to the left. Macro
mode uses a focal length of approximately 10 cm for
capturing close-up images.
● To use normal mode, slide the switch to the right.
Normal mode uses a focal length of approximately 50
cm for capturing images within a standard range of
distance from the camera.
Illuminates the keyboard in low-light conditions when the
keyboard light button is pressed.
Opens and turns on the keyboard light.
Allows a fingerprint logon to Windows instead of a password
logon.
Record sound and transmit sound for video conferencing.
