Display assembly

NOTE: All display assembly spare part kits include an ambient light sensor, fingerprint reader,
microphones, inverter board, WLAN antenna cables, and WWAN antenna cables
Description
Display assembly with camera and keyboard light
Display assembly with camera
Display assembly with keyboard light
Display assembly
Before removing the display assembly, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
5. Disconnect the wireless antenna cables from the WLAN module (see
and the WWAN module (see
6. Remove the following components:
a.
b.
c.
d.
Remove the display assembly:
1. Place the display into an upright position.
2. Disconnect the following cables from the system board:
(1) Fingerprint reader board cable
(2) Camera cable
(3) Keyboard light cable
62 Chapter 4 Removal and replacement procedures
Battery on page
Hard drive compartment cover (see
Keyboard (see Keyboard on page
Rear plastic bezel (see
Top cover (see Top cover on page
39).
WWAN module on page
Hard drive on page
50)
Rear plastic bezel on page
54)
Spare part number
454679-001
454675-001
454677-001
454676-001
WLAN module on page
47).
41)
52)
43)
