System board

NOTE: All system board spare part kits include replacement thermal material.
Description
Equipped with Intel Core Duo U7700 (1.33-GHz) processor (533-MHz FSB and 2-MB L2 cache)
Equipped with Intel Core Duo U7600 (1.20-GHz) processor (533-MHz FSB and 2-MB L2 cache)
Equipped with Intel Core Duo U7500 (1.06-GHz) processor (533-MHz FSB and 2-MB L2 cache)
Before removing the system board, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
5. Remove the following components:
a. Hard drive compartment cover (see
b. Keyboard (see
c. Rear plastic bezel (see
d. Top cover (see
e. Display assembly (see
When replacing the system board, be sure that the following components are removed from the defective
system board and installed on the replacement system board:
●
SIM (see
● Memory modules (see
●
RTC battery (see
●
Fan/heat sink assembly (see
●
Modem module (see
Remove the system board:
1. Position the computer with the left side toward you.
2. Press the ExpressCard slot bezel (1) to release it from the ExpressCard slot. (The ExpressCard
slot bezel is partially ejected from the ExpressCard slot.) The ExpressCard slot bezel is included
in the Plastics Kit, spare part number 454685-001.
Battery on page
Keyboard on page
Rear plastic bezel on page
Top cover on page
Display assembly on page
SIM on page 40)
Memory module on page
RTC battery on page
Fan/heat sink assembly on page
Modem module on page
39).
Hard drive on page 41)
50)
52)
54)
62)
49)
57)
71)
Component replacement procedures
Spare part number
469492-001
455083-001
455082-001
68)
65
