HP 2710p - Compaq Business Notebook Maintenance And Service Manual page 13

Category Description
WLAN options:
●
Broadcom 802.11a/b/g/n
●
Broadcom 802.11a/b/g
● Broadcom 802.11b/g
●
Intel 802.11a/b/g/n with iAMT support
●
Intel 802.11a/b/g with iAMT support
● Intel 802.11b/g
●
Supports no-WLAN option
●
Two dual-band 2.4-/5.0-GHz WLAN antennas built into display panel
WWAN options:
● Evolution-Data Optimized (EV-DO) Rev. A WWAN module
●
High-Speed Downlink Packet Access (HSDPA) WWAN module
●
Subscriber identity module (SIM)
● Two 5-band antennas built into display panel
Wireless personal area network (WPAN) options:
●
Bluetooth® module
●
Supports no-WPAN option
●
External media One 54-mm ExpressCard slot
card
● Integrated SD flash media slot (SD/MMC support)
●
Ports 1394a port
●
Digital erase pen
● Docking connector for HP 3-in-1 NAS Docking Station, HP Advanced Docking Station, HP Docking
Station, and HP External USB 2.0 MultiBay II Cradle
●
Headphone connector
●
Microphone connector
● Primary battery connector
●
RJ-11 modem port
●
RJ-45 Ethernet port
● SD card slot (SD/MMC support)
●
Smart AC adapter connector
●
Travel battery connector
●
USB ports (2 ports; one port is powered and is not available when the computer is docked)
● VGA port (Dsub 15-pin) supporting 1600 × 1200 external resolution @ 75 Hz, hot plug/unplug, and
auto detect
3
