Freecom VALUELOADER LTO User Manual page 72

Diagnostics and Troubleshooting
Removing Stuck Cartridges
Figure 17 Installing
the Carrier
58
After removing the cartridges from the desired carriers,
9
reinstall each carrier on the ValueLoader belt
sure of the following:
• That the rollers on the bottom of the carrier are aligned in
the carrier tracks.
• That the belt post beneath each carrier is inserted into the
proper ValueLoader belt loop.
There are unused loops on the belt. The proper belt
Note:
loops have an extra bump on the outside of the loop.
See figure
Ensure the carrier is properly installed on the belt by gently
10
pressing on the top of the carrier and sliding it back and forth.
If it is properly attached to the belt, it should not move. If it
moves, reinstall the carrier.
Replace the top cover of the ValueLoader and reinstall the
11
cover screws and mounting brackets (if rackmounted).
ValueLoader LTO Tape Autoloader User Manual
17.
(figure 17). Make
