System overview
Operation with Symphony Mesh
IP network
od5
Wall application examples
od5 with EB1E1A (1 input, 1 output, connected via USB)
Access door with
electric door opener
od5
od5 with EB3E2A-AUD (3 inputs, 2 outputs, connected via USB)
USB
Access door with
electric door opener
od5
od5 with IP Secure Connector (2 inputs, 3 outputs, network security and
PoE, connected via Ethernet)
Ethernet
Access door with
electric door opener
od5
od5
DATA SHEET V2.0/0224
The design and/or specifications of products may be subject to change for improvement without prior notice. Errors excepted.
ID5 TD CM
WS 303V CM
Protected interior area
EB1E1A
Protected interior area
EB3E2A-AUD
Protected interior area
IP Secure Connector
Security and Communication
Operation with Symphony On-Prem
od5
IP network
Intercom Server S3 or S6
Operation with Symphony Cloud
od5
ID5 TD CM
IP network
Mobile device
with Symphony Mobile Client
|
SA 5
Intercom stations and
Intercom modules
SIP stations
