Commend od5 Installation Instructions Manual page 10

Gypsum wall/panel mount kit XDX FB
Measuring units in mm (in), not to scale!
75 (2.95)
1)
84 (3.31)
Dimensions of the Intercom
2)
Cut-out for wall mounting station (see data sheet)
1)
Flush mount box XDX FBS
Measuring units in mm (in), not to scale!
92.5 (3.64)
NOTE:
For mounting of an Outdoor series Intercom station in the flush mount box
XDX FBS, the gypsum/panel mount kit XDX FB is required.
od5
DATA SHEET V2.0/0224
The design and/or specifications of products may be subject to change for improvement without prior notice. Errors excepted.
60 (2.36)
2)
40 (1.57)
Wall/panel thickness
3)
Dummy module for RFID readers XDX FBDUR
Measuring units in mm (in), not to scale!
75 (2.95)
2)
86 (3.39)
Projection on the wall
1)
Wall cutout
2)
Minimum mounting distance to Intercom station
3)
5 (0.2) to
3)
Security and Communication
11 (0.43)
1)
73 (2.87)
