Dimensions
od5
Measuring units in mm (in), not to scale!
86 (3.38)
Surface mount kit XDX SHE
Measuring units in mm (in), not to scale!
54 (2.13)
1)
60 (2.36)
2)
86 (3.39)
Dimensions for cable feed-through (ø 14 mm/0.55 in)
1)
Dimensions for mounting holes (ø 5 mm/0.2 in)
2)
Dimensions of the Intercom station (see data sheet)
3)
od5
DATA SHEET V2.0/0224
The design and/or specifications of products may be subject to change for improvement without prior notice. Errors excepted.
30
(1.18)
48
3)
(1.89)
Security and Communication
Surface mount kit XDX SH
Measuring units in mm (in), not to scale!
60 (2.36)
1)
86 (3.39)
Dimensions for wall holes (ø 5 mm/0.2 in)
1)
Dimensions of the Intercom station (see data sheet)
2)
Door mullion mount kit XDX SHMM
Measuring units in mm (in), not to scale!
12 (0.47)
7 (0.28) 16 (0.63)
84 (3.31)
1) Dimensions for boreholes
(ø 5 mm/0.2 in)
|
IN 2
23
2)
(0.91)
2
(0.08)
