Product details
Variants
OD5 TD CM
High-end outdoor Intercom station in silver.
Accessories
Gypsum wall/panel kit XDX FB
With the gypsum wall/panel mount kit XDX FB, an Inter-
com station can be installed e.g. in a drywall.
Flush mount box XDX FBS
With the flush mount box XDX FBS, an Intercom sta-
tion can be installed e.g. in a brick wall. The XDX FBS
is designed for wall mounting during the construction
or renovation phase. To mount the Intercom station,
the gypsum wall/panel kit XDX FB is required.
od5
DATA SHEET V2.0/0224
The design and/or specifications of products may be subject to change for improvement without prior notice. Errors excepted.
Security and Communication
OD5 TD CM-B
High-end outdoor Intercom station in black.
Surface mount kit XDX SH
With the surface mount kit XDX SH made of powder
coated stainless steel, an Intercom station can be
mounted on a wall. The XDX SH is primarily intended
for subsequent installation on a wall or for installation
on thin walls.
The surface mount kit XDX SH can be mounted to a
flush mount wall box (acc. EN 60670-1; 60 mm/2.36 in
screw distance; single or double box).
Surface mount kit XDX SHE
With the surface mount kit XDX SHE made of pow-
der coated stainless steel, an Intercom station can be
mounted on a wall. The XDX SHE is primarily intended
for subsequent installation on a wall or for installation
on thin walls. The XDX SHE provides extra space to
install accessories (e.g. EB3E2A-AUD, AFIL-USB,
TAMP-KIT, POE-SPLIT, PA25WPOE-DC or IP-BRIDGE).
|
SA 3
