Commend od5 Installation Instructions Manual page 7

od5
Technical specifications
Technical data od5
IP rating:
Driving rain resistance:
Mechanical impact resistance:
Salt spray test:
Front panel:
Microphone:
Loudspeaker:
Amplifier:
Sound pressure level:
Display:
Audio bandwidth:
Audio codecs:
Video features:
IT security:
Protocols: IPv4, IPv6, TLS, TCP, UDP, HTTP (RFC 2617, RFC 3310),
(RFC 5216), 802.1x EAP-MD5 (RFC 2284), RTCP, RTSP
Operating temperature range:
Storage temperature range:
Relative humidity:
Connections:
Power supply :
2)
Technical data camera
Image sensor:
Lens:
Minimum illumination:
Resolution (W x H):
Frame rate:
Video streaming: simultaneously up to 6 HTTP(S)/RTSP H.264 video streams with
and simultaneously up to 6 HTTP(S) MJPEG video streams with
od5
DATA SHEET V2.0/0224
The design and/or specifications of products may be subject to change for improvement without prior notice. Errors excepted.
IP65 (acc. to EN 60529)
acc. to CEN/TR 15601-D/B and
MIL-STD 810G Method 506.4/Proceduroe
OD5 TD CM: IK08 (acc. to EN 62262)
OD5 TD CM-B: IK07 (acc. to EN 62262)
672 h (acc. to IEC 60068-2-11/EN 9227)
hardened glass, AG85, 3 mm (0.12 in)
two digital MEMS microphones
special membrane type for optimal sound quality
integrated class-D amplifier with 2.5 W
max. 95 dB at 0.5 m (1.6 ft)/89 dB at 1 m (3.3 ft)
5" touch display (TFT)
resolution: 720 x 1280 pixel
luminance: typ. 680 cd/m
up to 20 kHz
Opus, G.722, G.711 a-law and G.711 u-law
codecs: H.264 (SIP video and ONVIF),
Motion JPEG (HTTP video and ONVIF) and RTSP
ONVIF specification: ONVIF Profile S
SIP over TLS, SRTP, IEEE 802.1X,
MJPEG via HTTPS, HTTPS for accessing the
web interface and interfaces
HTTPS (RFC 2818), RTP (RFC 3550), 802.1x EAP-TLS
(RFC 2326), DHCP, DHCPv6, DNSv4, DNSv6, mDNS,
SDP (RFC 2327, RFC 4566), SSDP, SIP (RFC 3261),
SIP over TLS, SNMPv2c, STUN (classicstun), SMTP,
DTMF Decoding (RFC 2976, RFC 2833, SIP Info),
ICMPv6 (Router discovery), MQTT (ISO/IEC 20922)
OD5 TD CM: –25 °C to +55 °C (–13 °F to +131 °F)
OD5 TD CM-B: –25 °C to +50 °C (–13 °F to +122 °F)
–25 °C to +70 °C (–13 °F to +158 °F)
up to 95%, not condensing
RJ45 jack for Ethernet and PoE (10/100 Mbit/s)
2 x 2.0 USB (Type A) for external devices
PoE: IEEE 802.3af/802.3at Type 1 Class 0
1/3 in RGB CMOS
F2.4, fixed aperture,
130° diagonal angle,
125° horizontal angle,
100° vertical angle
colour: 1.5 lux
1280 x 960 px
up to 30 fps
individual resolution or frame rate
individual resolution or frame rate
Power consumption:
Cabling:
Approvals and compliances:
Wall mounting:
2
Dimensions (H x W x D):
Colours:
Weight incl. packaging:
Optional accessories:
The USB connections are only intended for use with Commend devices. Do not use the USB jacks
1)
e.g. to charge mobile phones.
If a USB device should be installed separately using a USB extension cable, the USB cable length
must not exceed 5 m. In addition to that, it is recommended to attach a ferrite to a USB cable
with a length of 1 m or more. To comply with UL 62368-1 (cULus), the length of the USB cable
shall not exceed 3.05 m. All USB connectors are declared and proved PS1 USB ports (according
to the EN/UL/IEC 62368-1 standard).
2) For power supply, a PoE switch or PoE injector is required (not included in extent of supply), e.g.
IP Secure Connector.
3) The maximum line length of Cat. 5 cabling in a LAN is 100 m (328 ft) – e.g. from switch to
Intercom station.
1)
Extent of supply
– Intercom station
– Microfiber cloth
– TX 08 screwdriver
– Device identification document
– Open source compliance information
– Short reference
System requirements
B/W: 1 lux
Server
– VirtuoSIS (min. version 5.0) or
– S3/S6 (min. version 7 .1) or
– Compatible SIP server or
– Serverless operation
Configuration software
– Set-UP min. version 1.5.3
Security and Communication
idle: 3.1 W (without accessories)
max.: 12.8 W (full load, with accessories)
min. Cat. 5, shielded
EN 61000-6-2, EN 61000-6-3, EN 55032 Class B,
EN 55035, FCC Part 15 Class B, ICES-003 Class B,
IEC 60068-2-12, EN 60529 IP65, EN 62262 IK08,
EN 62368-1, IEC 62368-1 (CB Scheme),
UL 62368-1 (Listed E351589),
IEC/UL 60950-22 (outdoor, raintight)
gypsum wall/panel mount kit XDX FB
flush mount box XDX FBS (requires XDX FB)
surface mount kit XDX SH
228 x 86 x 11 mm (8.98 x 3.38 x 0.43 in)
with surface mount kit:
228 x 86 x 35 mm (8.98 x 3.38 x 1.38 in)
approx. 600 g (1.32 lbs)
AFIL-USB (induction loop kit)
EB1E1A (USB I/O module)
EB8E8A (USB I/O module)
EB3E2A-AUD (expansion module)
PA 25W POE-DC (power injector)
IP Secure Connector (safety switch box)
XDX FBDUR (dummy module for RFID readers)
| commend.com
TE 1
3)
with flush mount kit:
OD5 TD CM: silver
OD5 TD CM-B: black
