Removing the drawer cover caps
(Infinity)
Place a flathead screwdriver in the small
groove between the cover cap and the
drawer side and carefully twist. Keep the cap
in a safe place until it is needed again.
Adjusting the frontal
(Infinity)
Adjust the frontal to suit, as shown in the image.
Point 1 - Will adjust the frontal left and right.
Point 2a - Will lock/unlock point 2b.
Point 2b - Will adjust the frontal up and down.
Point 3 - Will adjust the frontal releasing
fixing clip. Screw while applying downward
pressure to release.
Fitting the drawer cover cap
(Infinity)
Position the cover cap over the mechanism,
aligning the clips on the cap with the cut-out
on the drawer side, and apply pressure.
