Wren Kitchens Infinity BASE UNIT Fittings Manual page 8

Securing to adjacent units
Clamp together the two units, checking the
front edges are level and flush.
Using the screws provided, 1x30mm screw
should be fixed into each corner of the unit
side.
The screws can be concealed by placing
them behind the shelf or behind the hinge
plates. The cover caps can be used to hide
any visible screw heads that remain.
Inserting the drawers
Slide the drawer onto the runner, making
sure the runner mechanism and the drawer
side grooves line up.
Once positioned on the runners, push the
drawer back into the unit. You will hear a click
when it is inserted correctly.
Adding the drawer buffers
Add 1x drawer buffer to each corner of the
unit, as shown in the image.
Page 8
