Adjusting the wall brackets
Using the points below to adjust the unit to
suit.
Place the cover cap once adjustment has
taken place.
A- Rotate the screw clockwise to move the
unit up. Anti-clockwise for down.
B- Adjust the depth using centre screw.
C- Screw the red screw until it touches the
plate to lock in position.
Place cover caps over the wall brackets.
Use a spirit level to ensure the units are level front to back, left to right and diagonally.
No screws or wall plugs are provided for attaching the unit to the wall.
Before drilling into the wall you MUST check for any hidden services or pipework within the walls.
Fixing the wall unit to the wall
Fix the unit to the wall through the gussets
using the appropriate screws to attach to the
wall.
Use cover caps to conceal the screws.
Double check units are level after adjustments.
This is due to variations in wall construction.
