Appendix B Radio Information
B.1 RF WWAN Specifications
The Regesta Smart v2 Nessum model, equipped with the EC25 module, provides network connectivity across vari-
ous radio frequency bands, adhering to the latest 3GPP standards, including:
• LTE (3GPP Release 10)
• DC-HSPA+ (3GPP Release 8)
• HSPA+ (3GPP Release 7)
• HSUPA (3GPP Release 6)
• HSDPA (3GPP Release 5)
• GSM, GPRS, EDGE (3GPP Release 99 with Feature Package#1)
Please note that antennas are not included with the product. Users are free to select compatible antennas, but it is
their responsibility to ensure that the chosen antennas comply with local regulations.
Technology: LTE.
Bands
Band 1
Band 3
Band 7
Band 20
Technology: UMTS(WCDMA)/ HSDPA/ HSUPA/ HSPA+/ DC-HSPA+.
Bands
Band 1
Band 8
Technology: GSM / GPRS / EDGE.
Bands
EGSM 900 (900 MHz)
DCS 1800 (1800 MHz)
Regesta Smart v2 Nessum
Frequencies
Tx: 1920-1980 MHz
Rx: 2110-2170 MHz
Tx: 1710–1785 MHz
Rx: 1805–1880 MHz
Tx: 2500–2570 MHz
Rx: 2620–2690 MHz
Tx: 832–862 MHz
Rx: 791–821 MHz
Frequencies
Tx: 1920-1980 MHz
Rx: 2110-2170 MHz
Tx: 880–915 MHz
Rx: 925–960 MHz
Frequencies
Tx: 880–915 MHz
Rx: 925–960 MHz
Tx: 1710–1785 MHz
Rx: 1805–1880 MHz
Conducted Transmit Power
+23 dBm ± 2 dB
+23 dBm ± 2 dB
+23 dBm ± 2 dB
+23 dBm ± 1 dB
Conducted Transmit Power
+24 dBm +1/-3 dB
+24 dBm +1/-3 dB
Conducted Transmit Power
+33 dBm ± 2 dB
+27 dBm ± 3 dB
+30 dBm ± 2 dB
+26 dBm ± 3 dB
