2 Product Overview
C
D
E
F
G
H
10
For more information about the CONF connector, please refer to:
- Console Connector as Serial Port (CONF Connector)
- Configuration Connector on page 33.
- Configuration Interface on page 35.
SFP/LAN3 Gigabit Ethernet SFP socket.
For more information about the WAN interface SFP socket, please refer to:
- SFP/LAN3 Connection on page 20
- SFP/LAN3 Socket on page 32
- SFP/LAN3 Interface on page 34
LAN1 Gigabit Ethernet port.
For more information about the LAN interface, please refer to:
- LAN1 and LAN2 Connection
- LAN1 and LAN2 Connectors
- LAN1 and LAN2 Interfaces
LAN2 Gigabit Ethernet port.
For more information about the LAN interface, please refer to:
- LAN1 and LAN2 Connection
- LAN1 and LAN2 Connectors
- LAN1 and LAN2 Interfaces
POWER. Power connection and Nessum signal injection for low voltage models.
For details on power connection options, please refer to:
- Power Source on page 18.
- Power Supply Specifications
For information on Nessum connection options, refer to:
- Nessum Connection on page 21.
- Nessum Interface on page 34.
Nessum. Two BNC connectors for injecting Nessum signals into medium voltage lines.
For more information about the Nessum connection options, refer to:
- Nessum Connection on page 21.
- Nessum BNC Connectors on page 33.
- Nessum Interface on page 34.
RF/WWAN antenna connectors for the Cellular interface, depending on the model.
For more information about the Cellular interface, please refer to:
- WWAN Antenna Connections (RF Connectors)
on page 24.
on page 20.
on page 32.
on page 34.
on page 20.
on page 32.
on page 34.
on page 35.
on page 22.
