4 Connecting the Router
Chapter 4 Connecting the Router
This chapter offers a comprehensive guide for connecting the Regesta Smart v2 Nessum router to Ethernet devices
and networks. It is divided into several sections for easy navigation and clarity:
4.1 Power Source
Note
Before connecting the router, please take the time to thoroughly read and follow the instructions out-
lined below.
4.1.1 Power Connector Pins
The power connector can be found on the router's connector panel.
Power Supply Connector
Fig. 14:
Depending on the model, the Regesta Smart v2 Nessum can be powered by either DC or AC.
Note
Ensure that the power requirements of your device match the power source.
The router uses a 5.08 mm pitch 2-wire terminal block for its power connection .
This connector features two terminals, designed for both AC power (in the AC or AC-powered MR models) and DC
power (in DC or DC-powered MR models).
18
•
Power Source
on page 18.
•
Data Connections
on page 20.
•
Installing the SIM Card
on page 24.
•
RST Button
on page 26.
•
Troubleshooting
on page 27.
•
Updating the Software
on page 27.
