A.2.5 Wireless WAN Interface
WWAN Standard/Bands
Speed (DL/UL)
CONNECTOR
SIM Slots
A.2.6 Configuration Interface
LOCAL TERMINAL
CONNECTOR
A.2.7 Power Supply Specifications
A.2.7.1 AC Model
NOMINAL
ABSOLUTE MAXIMUM
FREQUENCY
MAXIMUM POWER
CONNECTOR
Regesta Smart v2 Nessum
EC25-E:
• LTE:
• FDD. B1, B3, B5, B7, B8, B20
• TDD: B38, B40, B41
• WCDMA: B1, B5, B8
• GSM/GPRS/EDGE: 900/1800 MHz
EC25-E:
• LTE Cat 4.
• FDD. 150 Mbps/50 Mbps
• TDD: 130 Mbps/35 Mbps
• HSPA+ Cat 24/6: 42 Mbps/5.76 Mbps
• EDGE: 236 Kbps
Two optional RF SMA female connectors.
2 Mini-SIM slots (2FF) ISO/IEC 7810:2003, ID-000 (1.8 V / 3 V)
V.24 115200-8-N-1-without flow control.
RJ45 female on the connector panel.
110-240 V AC.
85-264 V AC.
50-60 Hz
10 W
2-pole 5.08 mm pitch terminal block.
