Lifting the Protective Case
Fig. 9:
To reattach the protective case, follow these instructions:
Slide the case back down into its original position:
Replacing the Protective Case
Fig. 10:
Lock the case in place by rotating the fastening mechanism back to a horizontal position and gently pushing down
until you hear a clicking sound.
Warning
Please ensure that the protective casing for the connectors is installed before powering on the device.
3.3 Installing a DIN Rail Mount Accessory
The Regesta Smart v2 Nessum can be easily installed on a standard DIN rail using the included mounting kit.
This kit provides all necessary components, including two screws for securely attaching the rail mount to the device.
The underside of the device has strategically placed holes that allow for flexible positioning of the DIN rail mount in
two possible positions:
