A.1.4 Configuration Connector
RJ45 CONFIGURATION
A.1.5 Nessum BNC Connectors
BNC
A.1.6 Power Supply Connector
2-wire terminal block with a 5.08
mm pitch
A.2 Technical Specifications
A.2.1 Hardware Architecture
MEMORY
STORAGE UNIT
Regesta Smart v2 Nessum
PIN
1
2
3
4
5
6
7
8
PIN
Internal
External
For AC models, Phase and Neutral connectors, while MR models for DC
supply use positive and negative connectors.
256 Mbytes in SDRAM.
FLASH Memory (4 Gbytes).
CONF
--
TxD (input)
GND
--
--
GND
RxD (output)
--
SERIAL
Nessum signal
GND
Technical Information
