Technical Information
Appendix A Technical Information
A.1 Connectors
A.1.1 LAN1 and LAN2 Connectors
RJ45 LAN
A.1.2 SFP/LAN3 Socket
SFP
A.1.3 WWAN/RF Connectors
Devices with this interface come with two SMA female connectors.
SMA Female
32
RJ45 PIN
1
2
3
4
5
6
7
8
PIN
Internal
External
FE Signals
BI-DA+
BI-DA-
BI-DB+
--
--
BI-DB-
--
--
Standard SFP socket
ANT
RF in/out
GND
GE Signals
BI-DA+
BI-DA-
BI-DB+
BI-DC+
BI-DC-
BI-DB-
BI-DD+
BI-DD-
