Page 2 This publication is subject to change. Teldat S.A. offers no warranty whatsoever for information contained in this manual. Teldat S.A. is not liable for any direct, indirect, collateral, consequential or any other damage connected to the deliv- ery, supply or use of this manual.
Page 3 4.1.2 Power Connector Cable ....... . Regesta Smart v2 Nessum...
Page 4 Nessum BNC Connectors ....... A.1.6 Power Supply Connector ....... Regesta Smart v2 Nessum...
Page 5 Radio Information ....... . . 37 RF WWAN Specifications ....... Regesta Smart v2 Nessum...
Page 6 The content in this manual applies specifically to the Regesta Smart v2 Nessum Series routers. 1.2 Who Should Read This Manual? This manual is designed for individuals who are installing and configuring the Regesta Smart v2 Nessum router for the first time. Installers should have a basic understanding of network structures, terminology, and concepts.
Page 7 1 About This Manual Teldat S.A. 1.8 Safety Warnings Connecting Dis- connecting "Conectar" "Desconectar" Regesta Smart v2 Nessum...
Page 8 1 About This Manual Teldat S.A. Regesta Smart v2 Nessum...
Page 9 1 About This Manual Teldat S.A. 1.9 Related Documentation Teldat Dm704-I Configuration and Monitoring Teldat Dm709-I LAN Interfaces Teldat Dm712-I SNMP Agent Teldat Dm781-I Cellular Interface Teldat Dm748-I Software Updating Teldat Dm753-I Syslog Client Teldat Dm1092-I Nessum Interface 1.10 Technical Support Contact information: Web: http://www.teldat.com...
Page 10 2 Product Overview Teldat S.A. Chapter 2 Product Overview This chapter provides an overview of the features of Regesta Smart v2 Nessum routers and their components. It in- cludes information on: • General Description on page 5. • Device Models on page 6.
Page 11 2.2 Device Models The table below details the various available models of the Regesta Smart v2 Nessum router. Two of these models feature BNC connectors to inject Nessum signals into medium voltage lines, while the other two models inject Nes- sum signals into low voltage lines via their power supply connector.
Page 12 Teldat S.A. - 72 VDC, 110 - 240 VAC). 2.3 Hardware Features The following information outlines the hardware features of the Regesta Smart v2 Nessum router. • PWR: External Power Input. • 2-Pole 5.08 mm Pitch Terminal Block Connector. • AC Power •...
Page 13 The device is registered, the PDP connection is established, and IP traffic can be transmitted through the CELLULAR inter- face. • Steady: No data transfer is occurring. • Flashing: Data is being transferred. Cellular interface Cellular interface is not active. corresponding to Regesta Smart v2 Nessum...
Page 14 RST. Reset button. For further details on the functionality of the reset button, please see RST Button on page 26. CONF. RJ45 connector providing access to the device's local console for configuration and monitoring purposes. This connector can also be used as an RS-232 asynchronous DCE serial port. Regesta Smart v2 Nessum...
Page 15 33. Nessum Interface on page 34. RF/WWAN antenna connectors for the Cellular interface, depending on the model. For more information about the Cellular interface, please refer to: WWAN Antenna Connections (RF Connectors) on page 22. Regesta Smart v2 Nessum...
Page 16 The platform on which the product information label is affixed. This label contains details such as the device model, MAC address, serial number, and more. 2.5 Power Supply The Regesta Smart v2 Nessum offers three distinct power supply options, depending on the specific model. Regesta Smart v2 Nessum...
Page 17 110-240 V AC and 48 V DC. 2.5.3 Dying Gasp Option The Regesta Smart v2 Nessum can be enhanced with an optional Dying Gasp board, which can send an alarm sig- nal in case of power failures or if the power supply cable is removed.
Page 18 3 Installing the Router Teldat S.A. Chapter 3 Installing the Router This chapter describes the steps to successfully install the Regesta Smart v2 Nessum router. It is divided into the fol- lowing sections: • Workplace Conditions on page 13. •...
Page 19 3 Installing the Router Teldat S.A. Removing the Protective Case Fig. 7: Slide the case up as shown below: Sliding the Case Up Fig. 8: Regesta Smart v2 Nessum...
Page 20 3.3 Installing a DIN Rail Mount Accessory The Regesta Smart v2 Nessum can be easily installed on a standard DIN rail using the included mounting kit. This kit provides all necessary components, including two screws for securely attaching the rail mount to the device.
Page 21 3.4 Wall Mounting For wall mounting, the Regesta Smart v2 Nessum comes with three dedicated mounting holes. To ensure a secure installation, screws should be inserted into these holes. Before attaching the device to the wall, make sure to remove the protective casing.
Page 22 3 Installing the Router Teldat S.A. Fig. 13: Holes for Wall Mounting. Regesta Smart v2 Nessum...
Page 23 4 Connecting the Router Teldat S.A. Chapter 4 Connecting the Router This chapter offers a comprehensive guide for connecting the Regesta Smart v2 Nessum router to Ethernet devices and networks. It is divided into several sections for easy navigation and clarity: •...
Page 24 Uninterruptible Power Supply (UPS), a regulated power supply, or is in- dependent of other power systems (such as lighting). Doing so helps to avoid malfunctions and prema- ture wear of drivers and other components. Regesta Smart v2 Nessum...
Page 25 The Regesta Smart v2 Nessum offers the following data connections. 4.2.1 LAN1 and LAN2 Connection The Regesta Smart v2 Nessum is equipped with two 10/100/1000 Base-T Gigabit Ethernet ports, which support automatic MDI/MDIX for seamless connection to a local area network (LAN).
Page 26 70 °C (160 °F) and be too hot to touch with bare hands. 4.2.3 Nessum Connection The Regesta Smart v2 Nessum features a High-Definition Power Line Communication (HD-PLC, now known as Nes- sum) interface, allowing seamless communication with compatible Nessum devices via power lines or coaxial cables.
Page 27 4.2.4 WWAN Antenna Connections (RF Connectors) Certain models of the Regesta Smart v2 Nessum router are equipped with a pair of RF antenna connectors. The an- tennas can be easily attached and detached by securely screwing or unscrewing them into the designated RF1 or RF2 connectors on the device's connector panel.
Page 28 For best results, it is recommended to use radio frequency accessories, such as antennas and cables, specifically endorsed by Teldat. Teldat offers a range of accessories, including 90º mount antennas, outdoor and ceiling installation antennas, exten- sion cables, and more. These accessories provide flexibility for installing the devices in various locations.
Page 29 4.3 Installing the SIM Card The Regesta Smart v2 Nessum includes a Wireless WAN interface that requires at least one SIM card for operation. However, in some countries, certain CDMA services offered by specific operators do not require a SIM card. The Regesta Smart v2 Nessum is equipped with two SIM trays located beneath the protective case, labeled SIM1 and SIM2.
Page 30 After removing the case, you will clearly see the elements illustrated below. The Regesta Smart v2 Nessum supports two SIM cards, offering flexibility for various configurations. For example, installing two SIM cards allows one to function as a backup. To configure this setup, each SIM card must be as- signed to its respective tray, as they have distinct configuration parameters.
Page 31 LAN1 port. 4.5 Dying Gasp Alarm The Regesta Smart v2 Nessum offers an optional board that triggers an alarm in the event of a power outage or if the power supply cable is disconnected.
Page 32 The Regesta Smart v2 Nessum router supports updating to the latest software releases. For detailed information about available updates, we recommend contacting your distributor. There are several methods for updating our routers. For step-by-step guidance, please refer to the “Teldat Dm 748-I Software Updating” manual.
Page 33 Typically, firmware is separate from the software. To ensure the correct update, consult your distributor for the appropriate UPGRADE file specific to your Wireless WAN module, as detailed in the “Teldat Dm781-I Cellular In- terface” manual, which offers instructions for module upgrades.
Page 34 RJ45 Ethernet cable. • Initiate a Telnet session from the IP terminal to the default IP address, 192.168.1.1 (for the Regesta Smart v2 Nessum). • No credentials (username/password) are required to access the console under the default configuration.
Page 35 +34 91 807 65 65 5.2 Intended Use of the Equipment The Regesta Smart v2 Nessum is designed specifically as an industrial router. Using this equipment in a residential setting may result in radio interference. 5.3 EC Declaration of Conformity (Non-Radio Version) English (EN) Teldat S.A.
Page 36 5.6 National Restrictions In accordance with Article 10 of Directive 2014/53/EU, we advise that there may be national restrictions and authoriz- ation requirements, which are subject to change. Teldat S.A. recommends consulting local authorities for the latest information regarding national regulations.
Page 37 BI-DA+ BI-DA- BI-DA- BI-DB+ BI-DB+ BI-DC+ BI-DC- BI-DB- BI-DB- BI-DD+ BI-DD- A.1.2 SFP/LAN3 Socket Standard SFP socket A.1.3 WWAN/RF Connectors Devices with this interface come with two SMA female connectors. SMA Female Internal RF in/out External Regesta Smart v2 Nessum...
Page 38 For AC models, Phase and Neutral connectors, while MR models for DC mm pitch supply use positive and negative connectors. A.2 Technical Specifications A.2.1 Hardware Architecture MEMORY 256 Mbytes in SDRAM. STORAGE UNIT FLASH Memory (4 Gbytes). Regesta Smart v2 Nessum...
Page 39 Standard for E1 interface (1.5 KV). A.2.4 SFP/LAN3 Interface STANDARDS 802.1Q (VLAN). 1000-Base-X. MSA and SFF 8472 compliant. SPEED 1000 Mbps full duplex. TYPES LX/LH (single-mode 1310 nm). SX (multi-mode 850 nm). ZX (single-mode 1550 nm). CONNECTOR Standard SFP socket. Regesta Smart v2 Nessum...
Page 40 RJ45 female on the connector panel. A.2.7 Power Supply Specifications A.2.7.1 AC Model NOMINAL 110-240 V AC. ABSOLUTE MAXIMUM 85-264 V AC. FREQUENCY 50-60 Hz MAXIMUM POWER 10 W 2-pole 5.08 mm pitch terminal block. CONNECTOR Regesta Smart v2 Nessum...
Page 41 LENGTH x WIDTH x HEIGHT 140 x 80 x 190 mm. WEIGHT 1 Kg. A.2.9 Environmental Specifications TEMPERATURE RANGE OPERATION: -20 °C to +70 °C STORAGE: -25 °C to +70 °C RELATIVE HUMIDITY 5 % to 93 % Regesta Smart v2 Nessum...
Page 42 Appendix B Radio Information B.1 RF WWAN Specifications The Regesta Smart v2 Nessum model, equipped with the EC25 module, provides network connectivity across vari- ous radio frequency bands, adhering to the latest 3GPP standards, including: • LTE (3GPP Release 10) •...
