CAUTION: Altering these switches from the specified settings may cause
damage to your system and void your warranty.
Table A–1 Factory Default Switch Settings
CPU/
MHz 1
EV6 SW1 Off
466
SW2 Off
SW3 On
EV67 SW1 Off
600
SW2 Off
SW3 On
Do not change the setting of the Timer jumper or any of the switches unless
they do not correspond to the settings shown in Figure A–6, or Table A–2.
The Halt/Reset Select jumper affects the operation of the control panel Halt
button. This jumper should be set to Halt for all operating systems
available on the DS10 and DS10L systems.
The RMC jumper enables or disables the remote management console.
Table A–2 Jumpers and Factory Default Positions
Halt/Reset Select
RMC
Timer
To change the jumper on the RMC jumper, wearing an anti-static strap, move
the pin to the position described in Table A-2.
2 3 4
On On Off
On Off Off
On Off On
On On Off
On Off On
On Off On
Default position
Set for Halt
To Enable RMC
To Disable RMC
Set for Enable Timer
5 6 7
Off On Off
On On Off
Off Off Off
Off Off On
Off Off Off
Off Off Off
Jumper
Pins 1-2
Pins 2-3
Pins 1-2
Hang jumper loose from pin 1;
do not jumper to pin 2.
Setting Jumpers A-11
