This appendix gives information on the correct settings of the jumpers on the
DS10/DS10L motherboard.
Sections include:
Warnings and Cautions
Remove Power from the System
Open the System
Remove the Floppy Disk Enclosure (DS10 only)
Set Jumpers
Restore Power
NOTE: In many ways the DS10 and DS10L systems are identical. This
manual uses DS10 systems for most illustrations and examples. Where
significant differences exist, an illustration or example of a DS10L is
presented separately.
