5 - Programmazione dati - Parameter programming
Descrizione colonne
DATE:
Data della registrazione
TIME:
Orario della registrazione
PROBE1 (0.1 °C): Temperatura sonda ambiente (IN_1)
STBY1: Impianto in Stand-by
EL1:
allarme di bassa temperatura ambiente
EH1:
allarme di alta temperatura ambiente
PROBE2 (0.1 °C): Temperatura sonda evaporatore (IN_2)
STBY2: Impianto in Stand-by
EL2:
non usato
EH2:
non usato
PROBE3 (0.1 °C): Temperatura sonda Datalogger (IN_3)
STBY3: Impianto in Stand-by
EL3:
allarme di bassa temperatura Datalogger
EH3:
allarme di alta temperatura Datalogger
DI1:
Ingresso digitale DI1 attivo (IN_4)
DI2:
Ingresso digitale DI2 attivo (IN_5)
DI3:
Ingresso digitale DI3 attivo (IN_6)
POWER-ON:
avvio
(registrazione
effettuata
indipendentemente dal parametro 'int': in questo modo è
possibile capire quando torna l'alimentazione all'impianto)
BATTERY: funzionamento a batteria attivo. Se BATTERY
= 1 manca l'alimentazione da rete; il controller continua a
registrare l'andamento della temperatura per circa 40 ore
(con batteria presente e carica).
AGGIORNAMENTO SOFTWARE – SOFTWARE UPDATE
E' possibile aggionare il software di controllo dei quadri
della linea PLUSR200 EXPERT in maniera automatica
tramite la porta USB utilizzata per scaricare i dati.
Per effettuare l'aggiornamento del software e' necessario:
Scaricare l'ultima versione disponibile dal sito
1.
www.pego.it, verificare che la Release sia
superiore a quella già presente nel PLUSR200.
2.
Inserire la memoria USB nello slot
quadro.
3.
Premere i tasti
selezionare la voce "Upd".
4.
Premere il tasto SET
controllore PLUSR200 EXPERT effettua in
automatico
l'esportazione
impostati, di tutti i dati in memoria (in formato pg2
e
csv),
poi
procede
l'aggiornamento.
L'aggiornamento cancella tutte le registrazioni della
memoria dati interna, mentre i parametri vengono
ripristinati ai valori precedenti l'aggiornamento.
Nota. Non scollegare mai la memoria USB e non togliere
l'alimentazione
al
quadro
dell'aggiornamento.
Rev. 01-17
del
PLUSR200
EXPERT
in
modo
asincrono
sul fronte
+
per 5 sec. e
per confermare. Il
dei
parametri
in
automatico
fino
al
temine
MANUALE D'USO E MANUTENZIONE
Columns Description
DATE:
Date of recording
TIME:
Time of recording
PROBE1 (0.1 °C): Ambient temperature (IN_1)
STBY1: Stand-by active
EL1:
ambient low temperature alarm
EH1:
ambient high temperature alarm
PROBE2 (0.1 °C): Evaporator temperature (IN_2)
STBY2: Stand-by active
EL2:
not used
EH2:
not used
PROBE3 (0.1 °C): Datalogger temperature (IN_3)
STBY3: Stand-by active
EL3:
Datalogger low temperature alarm
EH3:
Datalogger high temperature alarm
DI1:
Digital input DI1 active (IN_4)
DI2:
Digital input DI2 active (IN_5)
DI3:
Digital input DI3 active (IN_6)
POWER-ON: startup PLUSR200 EXPERT (recording
made asynchronously regardless 'int' parameter: by this
way you can understand when returns power to the
system )
BATTERY: battery mode active. If BATTERY = 1 power
supply is missing; the controller continues to record the
progress of the temperature for about 40 hours (with
battery charged) .
It is possible to update control software of PLUSR200
EXPERT line automatically via the USB port used to
download data.
To upgrade the software:
1.
Download latest version from www.pego.it, check if
the new Release is newer than the one inside
PLUSR200.
2.
Insert the USB memory in the slot on the front
panel .
3.
Press
the item "Upd".
4.
Press SET
PLUSR200 EXPERT automatically exports all
parameters, all data in memory (in csv and pg2
format), then proceeds automatically with the
con
update.
The update deletes all records of the internal data
memory, while the parameters take the values before
upgrading.
Note. Do not disconnect the USB memory and do not
remove the power supply until the update ends.
USE AND MAINTENANCE MANUAL
PLUSR200 EXPERT
+
for 5 sec and select
to confirm. The controller
Pag. 33
