5 - Programmazione dati - Parameter programming
- CSv: esportazione dati in formato testo
tabellare standard.
Confermare il salvataggio con il tasto
5.
Durante tutto il salvataggio compare la scritta
SAvE e la barra di stato nella parta alta del
display mostra lo stato di avanzamento del
salvataggio (15 step).
6.
Al termine del salvataggio viene emesso un
breve segnale sonoro.
7.
In caso di errore relativo alla memoria USB
viene emesso un segnale sonoro lungo e
visualizzata la scritta lampeggiante Err USB con
uno dei codici di errore di seguito riportati:
1 – disconnessione durante salvataggio /
memoria non collegata
2 – errore fisico / impossibile scrivere su disco
3 – percorso non valido
4 – accesso proibito
5 – unità in sola lettura
6 – file system non corretto / nome unità non
valido
7 – superato il limite di 999 file (pg2 o csv)
presenti su USB
8 – allarme USB generico
9 – errore di importazione parametri
8.
Nel caso di errore durante il salvataggio dati sarà
necessario rimuoverne la causa e ripetere
l'operazione.
9.
Rimuovere la USB dal quadro ed inserirla nel
computer.
10. Utilizzare la funzione Importa automatico del
TeleNET per una semplice importazione dei dati
in formato "pg2", o visualizzare i dati "CSv"
tramite un foglio di calcolo.
Fare riferimento al manuale del TeleNET per una maggiore
comprensione delle funzioni ed opzioni disponibili tra cui
l'importazione dei dati, la consultazione delle registrazioni
e degli allarmi, i grafici personalizzabili, l'identificazione
strumento univoca.
Nota. Il nome dei file *.pg2 e *.csv contiene il numero di
serie dello strumento. Al fine di consentire una corretta
importazione dei dati da parte del TeleNET è opportuno
non modificare i nomi dei file esportati.
Rev. 01-17
CSv: export data in standard tabular text
-
format.
Confirm saving with the key
.
5.
Throughout the save it shows the message SAvE
and the status bar at the top of the display starts
showing the progress of the saving (15 steps).
6.
After saving a short beep is emitted.
7.
If an error occurs on the USB memory a long
beep is emitted and the alarm Err USB flashes
with one of the error codes listed below :
1 – disconnection during saving / memory not
connected
2 – physical error / can not write to disk
3 – invalid path
4 – access forbidden
5 – unit in read-only
6 – incorrect file system / invalid device name
7 – exceeded the limit of 999 files (csv or pg2)
present on USB
8 – USB generic alarm
9 – parameter import error
8.
In case of error saving data you will need to
remove the cause and repeat the operation.
9.
Remove the USB from the panel and insert it into
your computer.
10. Use the Automatic Import function of TeleNET to
easy data import format "pg2" , or display data
"CSv " using a spreadsheet.
Refer
to
the
understanding of the functions and options available
including data import, consultation of records and alarms,
customizable graphs, identification tool unique .
Note. The name of the file *.pg2 and *.csv contains the
serial number of the instrument. In order to allow a correct
import of data from the TeleNET do not change the names
of the exported files.
MANUALE D'USO E MANUTENZIONE
USE AND MAINTENANCE MANUAL
PLUSR200 EXPERT
manual
of
TeleNET
for
Pag. 31
.
a
greater
