Mec Micro26-XD Operator's Manual page 8

Section 3 - Specifications
Height, Working
Maximum*
Height, Platform
Maximum
Height, Stowed
Maximum
Width
Platform Length
Maximum Occupants
(Indoor)
Maximum Occupants
(Outdoor)
Manual Force
Platform Dimensions (Length × Width)
Extension Deck Length
Platform Lift Capacity
Maximum Wind Speed
Wheelbase
Turning Radius
Pothole Ground
Clearance
Weight**
Controls
Power Source
Tire Size
Gradeability
Chassis Inclination
Drive Speeds
Maximum Wheel Load
Meets or exceeds the requirements of ANSI A92.20-2018 and CSA B354.6.17.
*Working Height adds 2 meters to platform height.
**Weight may vary with certain options or configurations.
Page 4
Specifications Specifications
Indoor
Outdoor
Indoor
Outdoor
Rails Up
Rails Folded
Retracted
Extended
Xtra Deck Deployed
Xtra Deck Stowed
Xtra Deck Deployed
Xtra Deck Stowed
Indoor
Outdoor
Outside
Inside
Retracted
Deployed
Platform Lowered
Platform Raised
Micro26 - XD - Operator's Manual - 96493
31.5ft 9.6m
23ft 7.0m
24.9ft 7.6m
16.4ft 5.0m
91.3in 2.32m
78.3in 1.99m
31.9in 0.81m
74in 1.88m
109.5in 2.78m
1 Person
2 Person
1 Person
1 Person
45lbs 200N
45lbs 200N
67.7×29.1in 1.72×0.74m
35.4in 0.9m
550lbs 250kg
28mph 12.5m/s
55.1in 1.4m
66.9in 1.7m
0 in 0m
3.8in 9cm
0.6in 1.6cm
4,453lbs 2,020kg
Proportional
24V DC
Φ323×125mm
12.7×4.9in
25% (14°)
1.5 Side, 3.0 Inline
2.8mph 4.5km/h
0.4mph 0.6km/h
1,496lbs 680kg
October 2024
