Section 5 - Xtra Deck Instructions
2. Lift the LH (Left Hand) inner rail followed by lifting the RH (Right Hand) inner rail.
3. While still on the ground, lift the Yellow Telescopic Rails and insert the front 2 Platform Floor Pins
(see image for location) near the floor.
4. Insert the 2 Entry Gate Pins (see image for location) on the gate and pull the top half of the gate
to an upward position.
5. Enter the platform.
6. Lift the Yellow Telescopic Rails to full height where they will lock in place.
7. Lift the Platform front panel.
8. Lower the Xtra Deck and install the 2 Telescopic Guardrail Pins (see image for location).
9. Lift the Xtra Deck back to the magnets.
10. Insert the 4 Platform Floor Pins (see image for location) near the floor.
11. Lower the Yellow Xtra Deck rails level with the main rails.
12. Set upper control box back on the Xtra Deck Yellow Telescopic Rails.
13. Return the extension deck to the stowed position.
