Section 8 - Operating Instructions and Function Tests
Test the Emergency Stop Function
1. Push in the ground red Emergency Stop switch to the Off position
(pushed in).
• Result: No functions should operate.
2. Pull out the ground red Emergency Stop switch to the On position (pulled
out).
Test the Horn
1. Push the horn button.
• Result: The horn should sound.
Test the Function Enable Switch and Platform Lift/Lower Functions
ART_6091
WARNING
1. Press the lift function select button.
2. Do not hold the Function Enable Switch on the control handle.
3. Slowly move the control handle forward/downward, then rearward/upward.
• Result: No functions should operate.
4. Press and hold the Function Enable Switch on the control handle.
5. Slowly pull the control handle rearward/upward.
• Result: The platform should raise. The pothole guards should deploy.
• Regardless of if the Function Enable Switch is pressed or released, if no machine movement
is made in 10 seconds then the current selection of Lift will time-out.
• Release then press the Function Enable Switch to reactivate selected function.
6. Release the control handle.
• Result: The platform should stop raising.
7. Press and hold the Function Enable Switch. Slowly push the control handle forward/downward.
• Result: The platform should lower. The descent alarm should sound while the platform is
lowering.
• Regardless of if the Function Enable Switch is pressed or released, if no machine movement
is made in 10 seconds then the current selection of Lift will time-out.
• Release then press the Function Enable Switch to reactivate selected function.
Test the Steering Functions
Note: When performing the steer and drive function tests, stand in the platform facing the steer end
of the machine.
1. Press the drive function select button.
2. Press and hold the Function Enable Switch on the control handle.
3. Depress the thumb rocker switch on top of the control handle in the direction
identified by the blue left arrow on the control panel.
• Result: The steer wheels should turn in the direction that the blue left arrow points on the
Page 21
Check the area above and around the machine for obstructions and
electrical power lines before operating the machine.
Micro26 - XD - Operator's Manual - 96493
October 2024
ART_5231
ON
OFF
Main Power/ Lower Emergency
Stop Switch
ART_5806
ART_5806
ART_5806
