Register
Byte Number
Bit Number
Description
Options Installed 7
57-59
N/A
60.
Radial interface 2/3
61
Radial interface 0/1
62 2 Port mux
63
CCS4S controller
Fault Status Mask
*
0 0-1
N'/A
2 Not used
3
Barrel 0 PP4 mask vector
4
Barrel 0 PP3 mask vector
5
Barrel 0 PP2 mask vector
6
Barrel 0 PPl mask vector
7
Barrel 0 PPO mask vector
1 8-9 N'/A
10
Not used
11
Barrel 0 PPll mask vector
12 Barrel 0 PPlO mask vector
13
Barrel 0 PP7 mask vector
14
Barrel 0 PP6 mask vector
lS
Barrel 0 PPS vector
16-17
N/A
18 Not used
19
Barrel 1 PP4 mask vector
20
Barrel 1 PP3 mask vector
21
Barrel 1 PP2 mask vector
22
Barrel 1 PPl mask vector
23 Barrel 1 PPO mask vector
3 24-2S N'/A
26
Not used
27
Barrel 1 PPll mask vector
28
Barrel 1 PPlO mask vector
29
Barrel 1 PP7 mask vector
30 Barrel 1 PP6 mask vector
31 Barrel 1 PPS mask vector
4
32
Channel 7 mask vector
33 Channel 6 mask vector
34 Channel 5 mask vector
35 Channel
4
mask vector
36 Channel 3 mask vector
37
Channel 2 mask vector
38
Channel 1 mask vector
39 Channel 0 mask vector
*
Register cleared by LOS.
Not used Bits are not assigned; may be read or written.
N'/A Bits not available will always be zero.
