SWITCHES AND INDICATORS
This subsection illustrates all system controls and indicators and defines
their functions. Figure 4-5 is a front view of the cabinet showing the
location of each major component and power module assembly. Figure 4-6 is a
rear view of the cabinet. Location of parts is indicated by find numbers in
figures 4-5 and 4-6 that are defined in table 4-2. Figure 4-7 shows the
control panel. Each major control in the panel is further illustrated and
defined by following figures and table pairs.
TABLE 4-2.
C~INET,
FRONT AND REAR VIEWS (SHEET 1 of 2)
I
Quantity
Find
I Part Description Per
Number l Number Assembl~
I
1
I 10389974 Protect module assembly 3
I
2
I
53370287 SPS meter assembly 1
I
3
I
53201796 Power supply interface 8
I
module assembly
I
4
I
67304098 Power control module 1
I assembly
I
5
I 5336 7198 Power control interface 1
I
6
I
15005280
Circuit breaker - 50/60 Hz
1
I
7
I
15005280
Converter input circuit
1
I
or breaker-(50/60 Hz or
I
15005255 400 Hz)
I
8
I
53370292 Fuse panel 2
I
9
I
53370288 Capacitor box assembly 1
I
10
I
53370206 Auxiliary power supply 1
I
regulator assembly
I
11
I
53370206 Bulk auxiliary power 1
I
supply
I
12
I
53370201 Converter assembly - 1
I
ac to de
I
13
I
53370246
Battery control box
1
I'
assembly
