CY180-810/830
POTENTIAL BAD PAKS
FSl BITS ERROR DESCRIPTION MODULE TYPE BO Bl B2 B3
32 ERROR ON CL CL IOU06 IOU06
33 ERROR ON CR CR IOU12 IOU13
34 FIRMWARE ERROR CP IOUll IOU14
35 ERROR ON CM CM IOU18 IOU19
36 ERROR ON CP
CP IOUll
IOU14
37
CONVERSION ERROR CP IOUll IOU14
39 PPM DATA IN ERROR CM IOU18 IOU19
CP -
IOUll IOU14
.45
0. S·. BOUNDS
CL IOU06 IOU06
VIOLATION CN IOU07 IOU07
46 O.S. BOUNDS CL IOU06 IOU06
ADDR. P.E.
CN IOU07 IOU07
48 C.M. DATA OUT ERROR DC MEM07 MEM07
49 UNCORRECTED CM DC MEM07 MEM07
WRITE ERROR CL IOU06 IOU06
so
UNCORRECTED CM
CL IOU06 IOU06
WRITE ERROR
CM IOU18 IOU19
51
CM REJECT ERROR DC MEM07 MEM07
CL IOU06 IOU06
52 CM TAG OUT ERROR DC MEM07 MEM07
CL IOU06 IOU06
53 CM RESPONSE ERROR DC MEM07 MEM07
CL IOU06 IOU06
CY180-65810/65830 POTENTIAL BAD PAKS
FSl BITS ERROR DESCRIPTION MODULE TYPE BO Bl
B2
B3
32 ERROR ON CL
CL IOU04 IOU04
33
ERROR ON CR CR IOUll IOU12
34
FIRMWARE ERROR CP
IOUlO IOU13
35 ERROR ON CM CM
IOU18 IOU19
36 ERROR ON CP
CP IOUlO IOU13
37
CONVERSION ERROR CP
IOUll IOU14
39 PPM DATA
IN
ERROR CM
IOU18 IOU19
CP IOUlO IOU13
45
O.S. BOUNDS CL
IOU04 IOU04
VIOLATION CN IOU
OS
IOU OS
46 O.S. BOUNDS
CL IOU04 IOU04
ADDR. P.E. CN IOU OS IOU OS
48 C.M. DATA OUT ERROR DC
MEM07 MEM07
49
UNCORRECTED CM DC MEM07 MEM07
WRITE ERROR CL IOU04 IOU04
50 UNCORRECTED CM
CL IOU04 IOU04
WRITE ERROR
CM IOU18 IOU19
51 CM REJECT ERROR
DC MEM07 MEM07
CL IOU04 IOU04
52 CM TAG OUT ERROR
DC MEM07 MEM07
CL
IOU04 IOU04
53
CM RESPONSE ERROR
DC
MEM07 MEM07
CL IOU04 IOU04
